900CR10-00 Honeywell 900 Control Station Operator Interface Module
Specifications
Manufacturer: Honeywell
Product No.: 900CR10-00
Condition： 10 العناصر الموجودة في المخزون
Product Type: Operator Interface Modules
Payment:T/T, Western Union
Weight: 360g
Shipping port: Xiamen
Warranty: 12 months
تفاصيل المنتج
وصف
Configured for process visualization, control execution, and diagnostics in Honeywell ControlEdge HC900 platforms, the Honeywell 900CR10-00 (900CR10 Operator Interface Module) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 900CR10-00 |
| Brand | Honeywell |
| Origin | USA |
| Dimensions | 10.4 in display panel mount footprint |
| Operating Temp | -10 to +60 deg C |
| Power Consumption | 10 to 30 VDC input range |
| Product Type | Operator Interface Modules |
| Display Type | 10.4 in TFT LCD (640 x 480 pixels VGA) |
| Touchscreen | Analog resistive touch panel |
| Processing Unit | ARM-based industrial CPU |
| Memory Storage | Internal flash memory; CompactFlash slot (up to 2 GB) |
| Serial Interfaces | 2 x RS-232, 1 x RS-422/485 |
| Network & USB | 1 x Ethernet (10/100Base-TX), 2 x USB (host/device) |
| Bezel Protection | NEMA 4X / IP66 front panel rating |
| System Compatibility | Honeywell ControlEdge HC900 |
4-20 mA HART Loop Protocol and Channel-to-Channel Isolation
The 900CR10-00 operator terminal interfaces directly with Honeywell HC900 controller racks to display real-time field data derived from 4-20 mA HART loop protocol transmitters and discrete I/O subsystems. Utilizing dedicated Ethernet and serial communications, the unit streams alarm summaries, historical data logging, and process recipes without introducing latency to primary loop execution. High-density isolation on physical interfaces protects the ARM-based processing core from common-mode electrical transients across distributed control system networks.
Frequently Asked Questions
Q: What programming tool is required to configure screens and trend logs on the terminal?
A: Screen configurations, recipe profiles, and data logging setups must be deployed using Honeywell Station Designer software version 3.1.7100 or later.
Q: What external storage media are supported for process data archiving?
A: Historical trends and alarm event logs can be recorded directly to an onboard CompactFlash card (up to 2 GB) or via external USB memory devices.
Q: Can the unit communicate simultaneously over serial and Ethernet connections?
A: Yes, the panel incorporates independent interface controllers allowing simultaneous operation over 10/100Base-TX Ethernet, dual RS-232 ports, and an RS-422/485 serial port.
Field Installation Guidelines
- Cut panel enclosure opening to match manufacturer cutout dimensions and ensure structural integrity before mounting.
- Verify that the front bezel sealing gasket is aligned flush against the panel surface to maintain NEMA 4X / IP66 ingress protection.
- Connect dedicated chassis ground conductors directly to the unit ground terminal using low-impedance copper wire.
- Route 10 to 30 VDC power conductors away from high-voltage motor or drive cabling to avoid electromagnetic interference.
