FS-SICC-0001/L11 | Honeywell | System Interconnection Cable

Specifications

  • Manufacturer: Honeywell

  • Product No.: FS-SICC-0001/L11

  • Condition： 10 العناصر الموجودة في المخزون

  • Product Type: System Interconnection Cables

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

تفاصيل المنتج

وصف

The Honeywell FS-SICC-0001/L11, also cataloged as the FS-SICC-0001 System Interconnection Cable, operates as a dedicated hardware component for multi-channel signal routing between modules and Field Termination Assemblies (FTAs) within Honeywell Safety Manager architectures.

Hardware Specifications

Parameter Specification
Model FS-SICC-0001/L11
Brand Honeywell
Origin USA
Weight Approx. 0.50 kg
Dimensions Outer Diameter: 9.93 mm (0.39 in), Cable Length: 11 m
Operating Temp -20 deg C to +85 deg C (-4 deg F to 185 deg F)
Power Consumption Passive component (Voltage Rating: 300 V)
Cable Type System Interconnection Cable
Conductor Configuration 20 x AWG 22 (0.34 mm2), Copper
Shielding Double shielded for EMI protection
Impedance 120 ohms
Termination Pre-terminated Honeywell-compatible connectors
Standard Compliance RoHS compliant, UL listed

4-20 mA HART Loop Protocol and Channel-to-Channel Isolation

The double-shielded construction of the FS-SICC-0001/L11 assembly preserves signal integrity across runs between control racks and termination units. High channel-to-channel isolation is maintained along the 20-conductor bundle, suppressing crosstalk between adjacent telemetry pathways. This shielding architecture attenuates external electromagnetic interference (EMI), ensuring high-fidelity transmission of analog measurement signals and digital communication over 4-20 mA HART loop protocol connections.

Frequently Asked Questions

Q: What is the primary physical difference between the L11 and L24 variants of this cable?

A: The FS-SICC-0001/L11 specifies an overall length of 11 meters, whereas the L24 variant specifies a length of 24 meters.

Q: How does the internal shielding prevent interference across signal pairs?

A: The assembly incorporates double shielding along its full 11 m length with a 120 ohm characteristic impedance match to suppress external noise.

Q: What operating temperature limits apply to field routing of this interconnect assembly?

A: The thermoplastic jacket and conductor insulation support continuous operational exposure from -20 deg C up to +85 deg C.

Field Installation Guidelines

  • Observe minimum static and dynamic bend radius limits corresponding to the 9.93 mm outer diameter during cable tray routing.

  • Fasten pre-terminated connector locking mechanisms securely to FTA interface headers to prevent pin contact oxidation or vibration loosening.

  • Verify shield continuity and ensure proper grounding at designated cabinet earth buses to avoid noise coupling and ground loops.

  • Avoid running system interconnect cables in close parallel proximity to high-voltage AC power distribution conduits.

Hot Tags :

Honeywell Safety Manager System Interconnection Cables
