Honeywell 51403645-500 Hard Disk Drive Module

The 51403645-500 from Honeywell is a hard disk drive module cataloged as an SBHM storage assembly for secure plant data logging within Honeywell TDC 3000 industrial control systems. This hardware component provides storage capacity to support data archival across distributed control environments.

System Integration and Isolation

This module incorporates channel-to-channel isolation within its interface architecture to ensure that data transfer between control subsystems remains unaffected by electrical noise or cross-talk. This isolation design helps maintain the integrity of logged process data during heavy industrial operation.

Specifications

Field Installation Guidelines

1. Mount the module securely in designated rack slots due to its weight.
2. Ensure vibration isolation to protect disk integrity in industrial environments.
3. Connect shielding layers to ground at a single point to minimize EMI.
4. Verify cabling alignment with TDC 3000 backplane connectors.
5. Maintain clearance for airflow to prevent thermal buildup.

Frequently Asked Questions

Q: What is the primary function of the 51403645-500 module?

A: It provides secure plant data logging and archival within Honeywell TDC 3000 systems.

Q: Is the module compatible with redundant system configurations?

A: Yes, it can be integrated into redundant architectures for high-integrity data storage.

Q: What is the approximate weight of the module?

A: The module weighs about 32 lbs (14.5 kg).
