Honeywell 900R12-0101 HC900 12-Slot I/O Slot Rack Assembly

Specifications

  • Manufacturer: Honeywell

  • Product No.: 900R12-0101

  • Condition： 10 العناصر الموجودة في المخزون

  • Product Type: I/O Slot Rack Assemblies

  • Payment:T/T, Western Union

  • Weight: 14050g

  • Shipping port: Xiamen

  • Warranty: 12 months

تفاصيل المنتج

وصف

The Honeywell 900R12-0101, also cataloged as the 900R12-0101 I/O Slot Rack Assembly, operates as a dedicated hardware component for physical module mounting and backplane bus signal distribution within ControlEdge HC900 hybrid controller architectures.

Hardware Specifications

Parameter Specification
Model 900R12-0101
Brand Honeywell
Origin USA
Weight 14.05 kg (30.98 lbs)
Dimensions Standard 12-position chassis footprint
Operating Temp 0 to +60 deg C
Power Consumption Backplane distributed 5 VDC / 24 VDC (2/6 Amp capacity)
Product Type I/O Slot Rack Assemblies
Position Capacity 12 Module Slots
System Compatibility Honeywell ControlEdge HC900 hybrid controller

Channel-to-Channel Isolation and 4-20 mA HART Loop Protocol

The backplane printed circuit assembly routes high-speed communication buses and power distribution rails across all 12 module slots while maintaining rigid physical separation between adjacent signal paths. Integrated ground planes and internal layout shielding suppress common-mode transient noise and cross-talk between high-density I/O slots. This electrical decoupling preserves signal integrity for distributed analog cards managing 4-20 mA HART loop protocol communications alongside high-voltage digital modules.

Frequently Asked Questions

Q: Does the 900R12-0101 rack assembly support online hot-swapping of modules?

A: Yes, individual I/O modules support hot-swapping within active rack positions provided that system backplane power is stable and standard electrostatic precautions are followed.

Q: How is operating power supplied to the 12-position rack backplane bus?

A: The chassis backplane receives regulated 5 VDC and 24 VDC power directly from attached HC900 power supply modules mounted within the rack assembly.

Field Installation Guidelines

  1. Ensure that main cabinet power feeds supplying the HC900 rack are locked out and de-energized prior to mechanical mounting.
  2. Secure the 12-slot chassis securely to the control cabinet backplate using mounting bolts through designated frame holes, ensuring clean metal-to-metal contact for earth bonding.
  3. Verify that backplane connector pins inside each of the 12 slots are straight and free of foreign debris before inserting any I/O cards or CPU modules.
  4. Route power supply and network cables through designated wire raceways, maintaining physical separation from high-voltage field wiring.
