Honeywell 900RTR-H001 ControlEdge HC900 Remote Terminal Panel

Specifications

  • Manufacturer: Honeywell

  • Product No.: 900RTR-H001

  • Condition： 10 العناصر الموجودة في المخزون

  • Product Type: Remote Terminal Panels

  • Payment:T/T, Western Union

  • Weight: 560g

  • Shipping port: Xiamen

  • Warranty: 12 months

تفاصيل المنتج

وصف

The Honeywell 900RTR-H001, also cataloged as the 900RTR Remote Terminal Panel, operates as a dedicated hardware component for relay output signal distribution and cabinet wiring field termination within ControlEdge HC900 systems.

Hardware Specifications

Parameter Specification
Model 900RTR-H001
Brand Honeywell
Origin USA
Product Type Remote Terminal Panels
System Architecture ControlEdge HC900
Function Remote Terminal Panel for Relay Output Modules
Voltage Range 5 to 250 VDC, 24 to 250 VAC
Contact Rating 2 A at 30 VDC, 0.5 A
Insulation Resistance Greater than 100 MΩ at 500 VDC
Operating Temp -20 to +70 deg C
Relative Humidity 5% to 95% non-condensing
Tariff Code 8537101190

Process Control & Network Integration

The remote terminal panel interfaces relay output channels to field final control elements through galvanically isolated signal routing circuits. Built-in high insulation resistance barriers prevent channel-to-channel isolation degradation under fluctuating electrical load conditions, supporting 4-20 mA HART loop protocol secondary control loops and high-voltage AC/DC contact execution without cross-channel noise coupling across HC900 backplane interfaces.

Frequently Asked Questions

Q: Is the 900RTR-H001 compatible with all HC900 I/O modules?

A: No, the 900RTR-H001 is specifically engineered for coupling with HC900 relay output modules; cross-referencing system schematics is required prior to deployment with digital or analog I/O cards.

Q: What insulation resistance rating is maintained by the terminal panel circuits?

A: The board maintains an insulation resistance exceeding 100 MΩ measured at 500 VDC to prevent current leakage between high-voltage switching channels.

Q: Does the unit require external DC operating power to drive internal logic?

A: The panel functions as a passive interface termination board, routing field contact voltages directly without drawing backplane logic current.

Field Installation Guidelines

  1. Disconnect all system and field excitation power sources prior to mounting or wiring the terminal panel assembly.
  2. Mount the panel inside a dry, clean industrial enclosure, preserving clearance around wiring channels for heat dissipation.
  3. Torque field terminal connections according to local electrical codes for specified 5-250 VDC and 24-250 VAC operating limits.
  4. Earth ground the panel chassis ground stud to the central cabinet bus bar to minimize electromagnetic interference.
  5. Practice ESD-safe handling procedures, including grounded wrist straps, during hardware installation.
