Honeywell CC-TDOD51 Experion PKS Series-C Digital Output Module

Specifications

  • Manufacturer: Honeywell

  • Product No.: CC-TDOD51

  • Condition： 10 العناصر الموجودة في المخزون

  • Product Type: Digital Output Modules

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 450g

  • Shipping port: Xiamen

  • Warranty: 12 months

تفاصيل المنتج

وصف

Configured for discrete load switching in Experion PKS Series-C control systems, the Honeywell CC-TDOD51 (CC-TDOD51 Digital Output Module) provides direct physical/electrical execution. It handles 32 open-drain sinking output channels across Input/Output Termination Assembly (IOTA) backplane networks.

Hardware Specifications

Parameter Specification
Model CC-TDOD51
Brand Honeywell
Origin USA
Weight 0.99 lbs (0.45 kg)
Dimensions 263 mm x 58 mm x 28 mm
Operating Temp -40 to +70 deg C
Power Consumption 200 mA at 24 VDC
Channels 32 discrete outputs
Output Type Sink (Open Drain)
Load Voltage 30 VDC maximum
Load Current 0.1 A per channel (maximum)
Protection Features Integrated short-circuit and over-voltage protection
Relative Humidity 0% to 95% non-condensing
Interface Type IOTA (Input/Output Termination Assembly)

Channel-to-Channel Isolation and Digital Load Management

The Honeywell CC-TDOD51 digital output module executes switching logic for up to 32 independent sinking channels rated at 30 VDC and 0.1 A per point. Integrated protection circuits safeguard field connections against short-circuit and over-voltage conditions, maintaining signal integrity across the backplane bus. The module interacts with field instrumentation loop architectures using software-configurable output parameters while isolating internal DCS logic from field-side voltage spikes and electrical transients.

Frequently Asked Questions

Q: Can the CC-TDOD51 digital output channels drive loads exceeding 0.1 A individually?

A: No, the maximum current rating is strictly 0.1 A per channel at 30 VDC. Exceeding this limit triggers internal short-circuit protection to protect channel circuitry.

Q: Is the CC-TDOD51 supported for live replacement on an energized IOTA base?

A: Yes, the module supports plug-in hot-swap capability on an active IOTA base without de-energizing adjacent system components or interrupting backplane communications.

Field Installation Guidelines

  1. Mount the IOTA base securely onto the cabinet DIN rail prior to module insertion.
  2. Align the CC-TDOD51 module connectors with the IOTA slot and push firmly until the latches lock into position.
  3. Verify that load voltage supplies do not exceed the 30 VDC limit for the open-drain sinking outputs.
  4. Route field digital output cabling through dedicated raceways physically separated from AC high-voltage lines by at least 200 mm to prevent noise coupling.
  5. Connect field cable shields to a dedicated cabinet grounding bar to ensure effective grounding and noise suppression.
