Honeywell DC-TAOX51 Analog Output Module
Specifications
Manufacturer: Honeywell
Product No.: DC-TAOX51
Condition： 10 العناصر الموجودة في المخزون
Product Type: Analog Output Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
تفاصيل المنتج
وصف
The DC-TAOX51 is an 8-channel analog output module manufactured by Honeywell for industrial automation and distributed control systems. It provides precision current and voltage control signals to field actuators and instrumentation, supporting selectable 12-bit or 16-bit resolution across configurable 0-20 mA, 4-20 mA, and 0-10 V output ranges. Operating on a nominal 24 VDC power supply, the unit maintains high measurement accuracy and channel isolation within standard control cabinet environments.
Output Configuration and Signal Performance
The module features 8 independently configurable output channels that deliver stable control signals with an accuracy of ±0.1% of full scale. In current output mode, it supports a maximum load resistance of up to 750 ohms, while voltage mode provides up to 10 VDC. The internal conversion circuitry achieves a fast response time of under 10 milliseconds for a 90% step change.
Environmental Limits and Physical Characteristics
Engineered for reliable panel-mount installation in industrial enclosures, the module operates in ambient temperatures from 0 deg C to +60 deg C and withstands storage conditions between -40 deg C and +85 deg C. It accommodates relative humidity levels from 5% to 95% non-condensing. The unit is protected by a channel-to-ground isolation rating of 500 VDC.
| Parameter | Specification |
|---|---|
| Model | DC-TAOX51 |
| Brand | Honeywell |
| Product Type | Analog Output Modules |
| Output Channels | 8 configurable outputs |
| Output Ranges | 0-20 mA, 4-20 mA, 0-10 V |
| Resolution | 12-bit or 16-bit (User-selectable) |
| Accuracy | ±0.1% of full scale |
| Current Output Load Resistance | Up to 750 ohms |
| Max Output Voltage | 10 VDC |
| Response Time | <10 ms (90% of step change) |
| Isolation Voltage | 500 VDC (Channel-to-ground) |
| Power Supply | 24 VDC nominal |
| Power Consumption | <5 W |
| Operating Temperature | 0 deg C to +60 deg C |
| Storage Temperature | -40 deg C to +85 deg C |
| Humidity Range | 5% to 95% RH (Non-condensing) |
| Module Dimensions (H × W × D) | 180 × 120 × 40 mm |
| Net Weight | 0.3 kg |
| Mounting Type | Panel mount |
Frequently Asked Questions
Q: What output ranges are supported by the Honeywell DC-TAOX51 module?
A: The module supports 0-20 mA, 4-20 mA, and 0-10 V configurable output ranges.
Q: What is the selectable resolution for the output channels?
A: Users can configure the module resolution to either 12-bit or 16-bit performance.
Q: What is the maximum load resistance in current output mode?
A: The current output mode supports a load resistance of up to 750 ohms.
