Honeywell FC-IOBUS-CPIO I/O Bus Extension Module

The Honeywell FC-IOBUS-CPIO, also cataloged as the FC-IOBUS-CPIO I/O Bus Extension Module, operates as a dedicated hardware component for inter-chassis signal extension and high-speed data transfer within Honeywell controller-to-I/O chassis platforms.

Hardware Specifications

Channel-to-Channel Isolation & 4-20 mA HART Loop Protocol

The FC-IOBUS-CPIO integrates channel-to-channel isolation circuits alongside advanced internal EMI/RFI shielding to maintain signal integrity during 100 kHz high-speed acquisition cycles. This physical isolation prevents noise injection, cross-talk, and ground loop interference from corrupting 0 to 21 mA analog signals and thermocouple measurement loops connected across expansion racks. By providing isolated signal execution paths, the module ensures transparent data passing for downstream 4-20 mA HART loop protocol instruments without introducing conversion latencies or signal degradation.

Frequently Asked Questions

Q: What communication protocols are natively supported by the module interface?

A: Native RS485 serial bus communication is supported, with extended compatibility for IOBUS-CPX, Ethernet, Modbus, and BACnet IP protocols when paired with an external converter.

Q: What input signal types can be wired to the module's 2 configurable I/O channels?

A: The channels support analog, digital, and thermocouple input configurations with high-speed signal processing capabilities up to 100 kHz.

Q: What physical mounting configurations are supported for control cabinet installation?

A: The enclosure supports standard DIN rail attachment as well as direct panel mounting via dedicated chassis retention points.

Field Installation Guidelines

1. Mount the module securely onto a grounded standard DIN rail or panel surface inside the enclosure using appropriate mounting hardware.
2. Verify that incoming DC supply power is switched off before connecting the primary 24 VDC (+/- 10%) terminal conductors.
3. Terminate RS485 bus lines and field I/O connections using shielded twisted-pair cabling to preserve internal EMI/RFI protection levels.
4. Ensure the cable drain wire is grounded directly to the cabinet central earthing bar to prevent high-frequency noise accumulation.
5. Maintain a minimum ventilation space around the module housing to facilitate natural thermal dissipation up to its 3.5 W rating.
