Honeywell FS-IOB-0001R Base I/O Module
Specifications
Manufacturer: Honeywell
Product No.: FS-IOB-0001R
Condition: 10 العناصر الموجودة في المخزون
Product Type: Base I/O Modules
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months
تفاصيل المنتج
وصف
The Honeywell FS-IOB-0001R, also cataloged as the FS-IOB-0001R Base I/O Module, operates as a dedicated hardware component for backplane bus routing, internal power distribution, and I/O module structural mounting within Honeywell Safety Manager platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FS-IOB-0001R |
| Brand | Honeywell |
| Origin | USA |
| Weight | Approx. 0.80 kg |
| Dimensions | Standard Safety Manager rack slot size |
| Operating Temp | 0 deg C to +60 deg C |
| Power Consumption | Passive bus backplane distribution (negligible internal dissipation) |
| Mounting Type | Rack-based cabinet installation |
| System Compatibility | Honeywell Safety Manager system architecture |
| Primary Function | Base backplane carrier and power interface for I/O modules |
4-20 mA HART Loop Protocol and Channel-to-Channel Isolation
The base module features dedicated backplane copper traces designed to maintain strict channel-to-channel isolation between installed I/O cards and field connection assemblies. Shielding paths integrated into the backplane layout prevent high-frequency noise and switching surges on auxiliary 24 VDC rails from interfering with analog instrumentation carrying 4-20 mA HART loop protocol signals.
Frequently Asked Questions
Q: Does removing or replacing an adjacent field module disrupt the backplane power rail on the FS-IOB-0001R?
A: No, the base module utilizes isolated internal power lines that allow individual field modules to be serviced without interrupting power or signal continuity on neighboring slots.
Q: How is structural grounding maintained across the rack assembly?
A: Frame grounding is established automatically through metal mounting hardware contacting the rack frame during mechanical insertion and screw retention.
Q: What power rails are distributed across the base module to individual slot connectors?
A: The module routes system logic supply voltages along with auxiliary 24 VDC field power lines directly from the chassis power supply units.
Field Installation Guidelines
- Ensure primary cabinet power feeds are de-energized or isolated prior to installing the base module onto the rack frame.
- Align the base carrier cleanly with chassis guide rails and secure retaining fasteners to verify structural grounding continuity.
- Inspect backplane bus connectors for bent pins or debris before plugging in downstream I/O modules.
- Maintain separate routing paths for high-voltage power lines and sensitive analog field signal cables entering the rack assembly.
