10201/1/1 Fail-Safe Digital Output Module | Honeywell

Specifications

  • Manufacturer: Honeywell

  • Product No.: 10201/1/1

  • Condition： 10 Artículos en stock

  • Product Type: Digital Output Modules

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 160g

  • Shipping port: Xiamen

  • Warranty: 12 months

Detalles de producto

Descripción

The 10201/1/1 from Honeywell is a fail-safe digital output module designed for critical safety control architectures within the Honeywell FSC system. This module delivers secure signal switching across eight channels, incorporating diagnostic and fault-tolerant features to maintain high operational reliability.

Output Architecture and Performance

This digital output module features eight channels divided into two galvanically isolated groups of four, supporting a maximum output current of 550 mA per channel at 24 VDC. It accommodates maximum lamp loads up to 120 mA while maintaining an off-state leakage current below 0.1 mA.

Specifications

Parameter Specification
Model 10201/1/1
Brand Honeywell
Product Type Fail-Safe Digital Output Module
Output Voltage 24 VDC
Output Channels 8 digital outputs (2 galvanically isolated groups of 4)
Max Output Current 550 mA per channel
Max Lamp Load 120 mA (2.9 W)
Voltage Drop < 2.0 VDC at 500 mA
Off-State Leakage Current < 0.1 mA
Power Requirements 5 VDC at 25 mA, 24 VDC internal/external at 2 x 35 mA
Module Size 4 TE, 3 HE (Eurocard format)
Mounting Rack-mounted with coded connectors
Weight 0.35 lbs

Frequently Asked Questions

Q: How are the output channels configured on the 10201/1/1 module?

A: It features eight digital output channels divided into two galvanically isolated groups of four channels each.

Q: What safety control platform is this module designed for?

A: It is engineered for critical safety applications within the Honeywell FSC (Fail Safe Controller) system.
