51195153-005 | Honeywell MU-NKD005 Experion PKS Coaxial Cable Set

The Honeywell 51195153-005, also cataloged as the MU-NKD005 Coaxial Cable Set, operates as a dedicated hardware component for high-frequency signal transmission and deterministic data routing within Honeywell Experion PKS and TDC 3000 control networks.

Hardware Specifications

Channel Isolation & FOUNDATION Fieldbus Connectivity

Designed with a high-density quad-shielded coaxial jacket, the assembly rejects electromagnetic interference (EMI) and radio frequency interference (RFI) generated by adjacent switching gear. Physical signal isolation prevents high-frequency carrier cross-talk, preserving loop timing integrity and carrier amplitudes when interfacing near high-density 4-20 mA HART loop protocol and FOUNDATION Fieldbus signal routing infrastructure.

Frequently Asked Questions

Q: Does the -005 suffix denote the physical length parameter for this assembly?

A: Yes, the -005 suffix designates the factory-terminated 5-meter physical length, engineered to maintain accurate network signal attenuation and characteristic impedance limits.

Q: Can the MU-NKD005 cable set be utilized in TDC 3000 Universal Control Network (UCN) links?

A: The RG6 coaxial cable set is fully compatible with TDC 3000 UCN nodes and Experion PKS communication buses requiring matching coaxial impedance characteristics.

Q: Is field crimping or length modification permitted on this coaxial cable set?

A: Cable sets feature factory-terminated precision connectors; cutting or field-crimping alters line impedance, causing signal reflection and packet transmission errors.

Field Installation Guidelines

• Do not exceed the minimum allowable bend radius during routing to prevent deformation of the RG6 dielectric insulator.
• Ensure factory-terminated coaxial connectors are fully torqued onto mating bulkhead receptacles to preserve shielding continuity.
• Route coaxial cable runs in dedicated low-voltage instrument trays separate from high-voltage AC power lines.
• Install cable runs inside metallic conduit if outdoor routing is necessary to prevent ultraviolet and mechanical damage.
• Maintain clean, moisture-free conditions on connector interfaces during installation to prevent signal attenuation.
