51402614-100 Honeywell TPS/LCN Ethernet Board

The 51402614-100 is an Ethernet board module designed by Honeywell to enable network connectivity for TPS/LCN operator and controller stations. Operating on a 5 VDC power supply with a low power consumption of max 3 W, this board-level module provides TCP/IP and ARP protocol support for data transfer across station architectures.

Network Communication and Interface

This board provides standard network interface capabilities to integrate Honeywell TPS and LCN stations into local networks. It supports data rates up to 10 Mbps using TCP/IP and ARP protocols to ensure reliable data transmission within control system hardware environments.

Power Requirements and Thermal Specifications

Designed for board-level installation inside host station hardware, the module draws power directly from a 5 VDC line with a tolerance of ±5%. It functions continuously within an operating temperature range of 0 deg C to 60 deg C (32 deg F to 140 deg F).

Specifications

The operational and physical parameters for this Ethernet module are detailed below.

Frequently Asked Questions

Q: What is the primary function of the Honeywell 51402614-100 Ethernet board?

A: It enables TCP/IP-based network communication for Honeywell TPS and LCN operator and controller stations.

Q: What power input is required for this module?

A: The board requires a 5 VDC (+/- 5%) power supply with a maximum power consumption of 3 W.
