Allen-Bradley 1790D-T16BV0 DC Compact Block LDX Module

Product Overview

The 1790D-T16BV0 is a high-performance 16-input DC compact block LDX module from AB Industries, designed to provide precise and reliable data acquisition for industrial control systems. Its compact and lightweight construction allows installation in space-constrained areas without sacrificing performance.

Engineered for efficiency, the 1790D-T16BV0 supports operating voltages from 12 to 24 VDC and consumes only ≤6mA per channel, helping reduce energy costs. With an operating temperature range from -20°C to +60°C and storage tolerance up to -40°C to +85°C, this module maintains stable performance in diverse environments.

Equipped with an RS-485 Modbus RTU communication interface, the module enables seamless integration with other industrial devices and systems, enhancing operational flexibility. Its modular design supports easy configuration and expansion to meet evolving automation needs.

Constructed from durable materials with advanced manufacturing processes, the 1790D-T16BV0 is built for long-term reliability and undergoes stringent quality control to ensure industry-standard performance.

Technical Specifications

Key Features

• Provides 16 digital DC inputs for accurate signal acquisition.

• Supports a wide 12–24 VDC operating range for diverse applications.

• Features low current consumption to improve energy efficiency.

• Compact, lightweight design for easy installation in constrained spaces.

• RS-485 Modbus RTU interface enables seamless system communication.

• Operates reliably in extreme industrial temperatures.

• Modular design supports expansion and easy configuration.

Typical Applications

• Industrial automation systems requiring precise data acquisition.

• Space-constrained installations demanding compact, lightweight modules.

• Integration with existing systems via RS-485 Modbus RTU communication.

• Manufacturing processes requiring efficient and reliable signal collection.

FAQ

Q1: Is the 1790D-T16BV0 module factory new and original?
A1: Yes, the 1790D-T16BV0 is 100% new and original from AB Industries.

Q2: How many inputs does the module support?
A2: It supports 16 DC input channels, ideal for compact block applications.

Q3: What is the operating voltage range?
A3: The module operates within 12–24 VDC, supporting a variety of industrial setups.

Q4: Does it have relay or analog outputs?
A4: No, the module focuses purely on 16 digital DC inputs.

Q5: What is the communication interface?
A5: It uses RS-485 Modbus RTU for seamless industrial device integration.

Q6: How durable is this module in extreme environments?
A6: It operates from -20°C to +60°C and stores safely up to -40°C to +85°C.

Q7: How long is the shipping time and which carriers are used?
A7: Orders ship in 3 days to 2 weeks, depending on quantity, via carriers like DHL.

Q8: What if a quality issue arises?
A8: We support 30-day returns for verified product quality concerns.
