ProSoft 3150-MCM Allen-Bradley Modbus Communication Module

Product Overview

The ProSoft 3150-MCM is a highly efficient Modbus Communication Module designed for seamless integration with Allen-Bradley PLC systems. This single-slot module features two configurable RS232 / RS422 / RS485 communication ports, supporting both Modbus Master and Modbus Slave protocols.

Capable of handling up to 4000 registers, the 3150-MCM supports various data types, including binary, integer, ASCII, and floating-point. It facilitates smooth data exchange between Modbus-enabled devices and the Allen-Bradley PLC platform.

With a range of customizable settings, this module supports user-definable memory mapping for optimized configuration. Its extensive functionality ensures maximum flexibility for a variety of industrial automation applications.

Key Features

• Manufacturer: ProSoft

• Model: 3150-MCM

• Product Type: Modbus Communication Module

• Communication Ports: Two (2) RS232 / RS422 / RS485 ports

• Protocols Supported: Modbus Master / Slave

• Registers: Up to 4000 registers

• Data Types: Binary, Integer, ASCII, Floating-point

• Power Supply: 12-24V DC External

• Configuration: Ladder logic programming

• Shock Rating: 30G Operational

• Compatible with: Allen-Bradley PLC systems

Technical Specifications

Features and Benefits

• Dual Communication Ports: The 3150-MCM features two RS232 / RS422 / RS485 ports, making it flexible and compatible with a wide range of devices.

• Up to 4000 Registers: Supports extensive data storage and transfer, enhancing system capacity for complex industrial processes.

• Modbus Master and Slave Protocols: Offers full support for both Modbus Master and Modbus Slave communication, ensuring versatility in various applications.

• User-Definable Memory Mapping: Custom memory mapping capabilities provide enhanced control over data management and system optimization.

• Industrial Durability: Built to handle tough industrial environments with a 30G shock rating, ensuring reliable performance even under harsh conditions.

• Wide Data Type Support: Transfers multiple data types, including binary, integer, ASCII, and floating-point, enhancing its flexibility across different applications.

Applications

The ProSoft 3150-MCM is ideal for applications that require seamless Modbus communication between Allen-Bradley PLCs and Modbus-enabled devices. Common applications include:

• Industrial Automation

• Data Concentration Systems

• Pipeline Monitoring

• SCADA Systems

• Manufacturing Systems

• Process Control Systems

FAQ

Q1: What communication protocols does the 3150-MCM support?
A1: The ProSoft 3150-MCM supports both Modbus Master and Modbus Slave protocols, offering flexible communication options.

Q2: How many registers can the 3150-MCM handle?
A2: The 3150-MCM can handle up to 4000 registers, ensuring ample space for data storage and transfer.

Q3: What are the supported data types for the 3150-MCM?
A3: The 3150-MCM supports binary, integer, ASCII, and floating-point data types.

Q4: How is the 3150-MCM configured?
A4: The module is configured using ladder logic programming, providing ease of integration with Allen-Bradley PLC systems.

Q5: What is the shock rating for the 3150-MCM?
A5: The 3150-MCM has a 30G operational shock rating, ensuring its durability in industrial environments.
