Prosoft MVI56-DFCM Master/Slave Communication Module

Product Overview

The Prosoft MVI56-DFCM is a versatile and high-performance Master/Slave Communication Module designed to ensure efficient and reliable data exchange in complex industrial control systems. Compatible with Modbus RTU and ASCII protocols, this module facilitates smooth integration across various industrial environments, enhancing system interoperability.

Its compact design and backward compatibility make it a robust solution for both existing systems and new deployments, optimizing network resources and streamlining data transfer. The MVI56-DFCM excels in providing real-time data handling for precise process control and monitoring.

Key Features

• Communication Protocol: Supports Modbus RTU and ASCII, ensuring broad compatibility with industrial systems.

• Number of Channels: 2 independent channels for efficient data handling.

• Data Transfer Rate: Supports speeds from 9600 bps to 115200 bps, offering flexibility in network speeds.

• Power Consumption: Low power usage of ≤ 3W ensures efficient operation in energy-sensitive applications.

• Temperature Range: Operational range from -20°C to +70°C and storage range from -40°C to +85°C, suitable for various industrial environments.

• Compact Size: 84mm x 56mm x 27mm ensures easy integration into tight spaces.

• Weight: Lightweight at 65g, making installation and maintenance hassle-free.

• Backward Compatibility: Seamlessly integrates with older Prosoft models, minimizing the need for reprogramming during upgrades.

Technical Specifications

Applications & Functions

The MVI56-DFCM module enhances industrial automation by enabling efficient communication between control systems and devices. It supports data movement for 16-bit integers and floating-point data, ensuring high precision in control and monitoring processes. Its modular design also allows it to manage up to 15 devices per HART channel, optimizing network utilization and reducing latency.

Ideal for industries requiring high-performance communication and precise data handling, the MVI56-DFCM module is commonly used in:

• Manufacturing Automation

• Oil & Gas Control Systems

• Chemical Processing Plants

• Power Generation Systems

• Process Control Systems

FAQ

Q1: What communication protocols does the MVI56-DFCM support?
A1: The MVI56-DFCM supports Modbus RTU and ASCII, making it compatible with a wide range of industrial systems.

Q2: How many channels does the MVI56-DFCM support?
A2: The MVI56-DFCM features 2 independent channels, allowing efficient management of multiple devices.

Q3: What is the operating temperature range of the MVI56-DFCM module?
A3: The MVI56-DFCM operates in temperatures ranging from -20°C to +70°C, with storage temperatures from -40°C to +85°C.

Q4: How does the MVI56-DFCM optimize data transfer?
A4: The module supports a data transfer rate of 9600 bps to 115200 bps, ensuring efficient communication even in high-speed networks.

Q5: Is the MVI56-DFCM backward compatible?
A5: Yes, the MVI56-DFCM is backward compatible with older Prosoft models, allowing for smooth upgrades with minimal reprogramming.
