Allen-Bradley 2094-BM01-M Kinetix 6000 Axis Module

Product Overview

The 2094-BM01-M from Allen-Bradley is a Kinetix 6000 Axis Module designed for precise motion control applications. This module operates at 400VAC with a continuous current of 6.1 A and a peak current of 15.3 A. It delivers a high efficiency of 98%, ensuring energy savings and optimal performance.

This axis module is installed directly on the Kinetix drive power rail, typically positioned alongside the Integrated Axis Module (IAM). It interfaces with motors and motion devices using feedback cables, auxiliary feedback, I/O connections, and safety wiring. Additionally, it supports integration of control modules for enhanced system functionality.

Engineered for industrial environments, the 2094-BM01-M is suitable for continuous operation at temperatures from 0°C to 50°C (32–122°F). Its short-circuit current rating reaches 200,000 A (rms) symmetrical, providing robust protection in high-demand applications.

Technical Specifications

Key Features

• High-efficiency axis module with 98% energy conversion.

• 400VAC voltage class supports industrial-grade drives.

• Robust peak current capacity of 15.3 A for transient loads.

• Direct installation on Kinetix power rail for secure mounting.

• Interfaces with motors, I/O, safety wiring, and feedback devices.

• Designed for continuous operation in temperatures up to 50°C.

Applications

• Industrial motion control systems

• Servo motor drive integration

• High-performance Kinetix 6000 drive applications

• Automated manufacturing and robotic systems

FAQ

Q1: Is the 2094-BM01-M original and factory-new?
A1: Yes, the 2094-BM01-M is 100% original Allen-Bradley, factory-sealed.

Q2: What is the continuous current rating?
A2: This module provides 6.1 A continuous with a peak of 15.3 A.

Q3: What is the operating temperature range?
A3: It functions reliably from 0°C to 50°C (32–122°F).

Q4: How is the module installed?
A4: The 2094-BM01-M mounts directly on the Kinetix power rail.

Q5: What is its efficiency rating?
A5: The module achieves 98% efficiency for energy savings.

Q6: How quickly can it ship?
A6: Typical delivery is 3 days to 2 weeks, depending on order size and logistics.

Q7: Can it be returned if defective?
A7: Yes, we provide 30-day returns for verified quality issues.
