2711P-T6C20D8 | Allen-Bradley | PanelView Plus 600 Touch Display Module

Overview

Manufacturer: Allen-Bradley
Product No: 2711P-T6C20D8
Product Type: PanelView Plus 600 Touch Display Module

Product Details

• 2711P-Bulletin:

  • T: Touch
  • 6: 5.7 in
  • C-Display Type: Color
  • Communication-20: Ethernet, RS-232, USB
  • D: DC
  • 8 - Operating System: Windows CE 6.0

• PanelView Plus 6 - 600 Terminals:

  • Without Extended Features

• Cat. Nos.:

  • Keypad: 2711P-K6C20D8
  • Touch: 2711P-T6C20D8
  • Keypad and Touch: 2711P-B6C20D8

Display Specifications

• Size: 5.7 in
• Type: Color

Communication Ports

• RS-232
• Ethernet

USB Ports

• Host/Device

Input Power

• DC

Memory Specifications

• RAM: 256 MB
• Nonvolatile: 512 MB (approx. 73 MB free user memory)

Display Area

• Dimensions (WxH): 115 x 86 mm (4.5 x 3.4 in.)

Weight

• Keypad: 728 g (1.60 lb)
• Touch: 594 g (1.31 lb)

Dimensions

• Keypad (HxWxD):
  • Without AC Module: 167 x 266 x 68 mm (6.58 x 10.47 x 2.68 in.)
  • With AC Module: 167 x 266 x 98 mm (6.58 x 10.47 x 3.86 in.)
• Touch (HxWxD):
  • Without AC Module: 152 x 185 x 68 mm (6.0 x 7.28 x 2.68 in.)
  • With AC Module: 152 x 185 x 98 mm (6.0 x 7.28 x 3.86 in.)

Cutout Dimensions

• Keypad (HxW): 142 x 241 mm (5.61 x 9.50 in.)
• Touch (HxW): 123 x 156 mm (4.86 x 6.15 in.)
