80363972‑100 | Honeywell | MU-PDIY22 Digital Input Module
Specifications
Manufacturer: Honeywell
Product No.: MU-PDIY22 80363972-100
Condition: 10 Items in Stock
Product Type: Digital Input Modules
Product Origin: USA
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
The Honeywell 80363972-100, also cataloged as the MU-PDIY22 Digital Input Module, operates as a dedicated hardware component for binary status acquisition and signal processing within Honeywell Series 8 and Experion PKS platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MU-PDIY22 |
| Brand | Honeywell |
| Origin | USA |
| Weight | 0.55 kg |
| Dimensions | Standard Series 8 rack slot dimensions |
| Operating Temp | 0 to 50 deg C |
| Power Consumption | Standard backplane bus load |
| Part Number | 80363972-100 |
| Input Channels | 32 isolated digital inputs |
| Signal Type | 24 VDC logic level |
| Isolation Voltage | 2 kV AC channel-to-system isolation |
| System Compatibility | Honeywell Series 8 / Experion PKS |
Channel-to-Channel Isolation & Signal Conditioning
The module incorporates optocoupler barriers to maintain 2 kV AC channel-to-system isolation across all 32 digital input circuits. This galvanic separation prevents ground loops and high-voltage surges from propagating to the Experion PKS controller backplane. When installed adjacent to 4-20 mA HART loop protocol field wiring, onboard hardware filters suppress line noise and contact bounce to preserve accurate sequence-of-events logging and interlock state evaluation.
Frequently Asked Questions
Q: Does the MU-PDIY22 module supply wetting voltage for the field contacts?
A: No. The 32 digital input channels require an external 24 VDC loop power supply to energize the dry contact circuits back to the module input terminals.
Q: What precautions are necessary when hot-swapping or servicing the module?
A: Adhere to Experion PKS maintenance guidelines; field 24 VDC contact power should be isolated before extracting the module or disconnecting terminal blocks to prevent false signal transitions.
Q: How does channel-to-system isolation protect the controller backplane?
A: Optical isolation barriers physically break electrical continuity between field wiring and the internal bus, blocking voltage spikes up to 2 kV AC.
Field Installation Guidelines
- Isolate main cabinet power and external 24 VDC field loop supplies before inserting the module into the Series 8 chassis slot.
- Align the module printed circuit board edge connector with card guides and seat the unit firmly until the latch engages.
- Tighten upper and lower module retaining screws to guarantee mechanical integrity and continuous chassis ground bonding.
- Route 24 VDC field input wiring in dedicated low-voltage wire ducts separate from AC power conductors to prevent inductive coupling.
- Connect field cable overall shield drain wires to the primary cabinet ground bus bar at a single termination point.
