AB 41391-454-01-S1FX | Electrical Control Module

Overview

The AB 41391-454-01-S1FX is an SMC Flex standard electrical control module designed for soft starter applications. It serves as a replacement or alternative control module in industrial settings, offering quick-start and standard control capabilities.

Power and Electrical Ratings

This control module operates at 100 Volts AC and can handle 24 Amperes at 480 Volts. It supports output voltages from 100 to 240 Volts AC and output currents between 5 and 1250 Amperes, making it compatible with solid-state motor controllers.

Design and Indicators

The 41391-454-01-S1FX has a white-grey exterior with a front panel that includes up to four LED indicators for device and diagnostic status. It also features a display screen and push buttons for enhanced control options. Electrical connections are located at the bottom of the panel for easy access.

Certification and Safety

This module is CE certified and approved by KC and cULus for compliance with international safety standards. It ensures reliable operation in industrial environments while meeting rigorous safety requirements.

Environmental Specifications

The AB 41391-454-01-S1FX functions in temperatures from -5 to +50 °C (23 to 122 °F) in open conditions, and -5 to +40 °C (23 to 104 °F) when enclosed. It can operate at altitudes up to 2000 meters (6560 feet) without de-rating, and supports 5–95% non-condensing relative humidity.

Dimensions and Weight

This control module measures 40 × 33 × 8.8 cm and weighs 0.9 kg, allowing easy integration into existing SMC-Flex installations.

Applications

The 41391-454-01-S1FX is ideal for use in:

• SMC-Flex soft starter systems

• Industrial motor control applications

• Repair and replacement in existing automation setups
