ABB DI581-S 1SAP284000R0001 Industrial Control Module

Product Overview

Extended Product Type: DI581-S
Product ID: 1SAP284000R0001
ABB Type Designation: DI581-S
EAN: 4016779681797
Catalog Description: Digital input module. Safety. 16SDI, 16SDI SIL2/8SDI SIL3, 24VDC, 1-wire, 8 pulse output (DI581-S)
Long Description: DI581-S: S500-S Digital input module. Safety. 16SDI, 16SDI SIL2/8SDI SIL3, 24VDC, 1-wire, 8 pulse output.
Invoice Description: Digital input module. Safety. 16SDI, 16SDI SIL2/8SDI SIL3, 24VDC, 1-wire, 8 pulse output (DI581-S)
Made to Order: No
Minimum Order Quantity: 1 piece
Order Multiple: 1 piece
Selling Unit of Measure: Piece

Technical Specifications

• Function: Safety. 16SDI, 16SDI SIL2/8SDI SIL3, 24VDC, 1-wire, 8 pulse output

• Number of Digital Inputs: 16

• Number of Digital Configurable I/Os: 0

• Input Voltage Type: DC

• Input Current: 7 mA

• Maximum Input Voltage: 0 ... 30 V

• Delay Time (τ): 1 … 500 ms

• Degree of Protection: IP20

• Safety Integrity Level (SIL): 2

Dimensions

• Product Net Weight: 0.122 kg

• Product Net Depth / Length: 62 mm

• Product Net Height: 76 mm

• Product Net Width: 67.5 mm

• Gross Weight: 0.151 kg

Packaging Dimensions

• Package Level 1 Depth / Length: 84 mm

• Package Level 1 Height: 72 mm

• Package Level 1 Width: 71 mm

• Package Level 1 Units: 1 carton

Certifications and Declarations

• Declaration of Conformity - CE: 3ADR980142

• REACH Date: 20241206

• REACH Declaration: 3ADR980139

• REACH Information: Contains substances > 0.1 mass percentage

• SCIP: 34c5ffa9-2ff5-4778-8ac9-e57fb41dd664 (Germany)

• RoHS Date: 2011

• RoHS Information: 3ADR980142

• RoHS Status: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

External Classifications and Standards

• eClass: 27-24-22-02

• ETIM 8: EC001419 - PLC digital I/O-module

• ETIM 9: EC001419 - PLC digital I/O-module

• ETIM 10: EC001419 - PLC digital I/O-module

• UNSPSC: 32151802

Environmental Information

• WEEE B2C / B2B: Business To Business

• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Additional Information

• Product Main Type: DI581

• Product Name: Distributed Automation I/Os
