ABB MB810 HPC800 Module Termination Unit

Description

The ABB MB810 is a termination and mounting unit designed for HPC800 modules within Symphony Plus control systems. It provides a secure base for module installation and electrical interfacing in distributed automation environments.

Specifications

• Manufacturer: ABB

• Model Number: MB810

• Product Type: Module Termination Unit

• System Compatibility: Symphony Plus HPC800

• Mounting Locations: A = HC800, B = CP800

• Product Net Depth: 243.84 mm

• Product Net Height: 73.66 mm

• Product Net Width: 170.18 mm

• Net Weight: 1.43 kg

• Mounting Type: DIN rail or panel-mounted

• RoHS Status: No declaration needed

• Country of Origin: Sweden

• Condition: New and in stock

Features

• Secure Module Mounting: Provides stable mechanical and electrical support for HPC800 modules

• System Integration: Designed for use with ABB Symphony Plus distributed control systems

• Compact Design: Optimized dimensions for efficient cabinet layout

• Flexible Mounting Options: Supports DIN rail and panel installation

• Industrial Durability: Built for long-term use in demanding automation environments

• Global Compliance: Meets international standards for control system hardware

• Simplified Wiring: Facilitates organized and accessible module connections

• Reliable Performance: Ensures consistent operation of control and communication modules
