Allen-Bradley 1492-AIFM6TC-3 Analog I/O Module for Thermocouples

Product Overview

The Allen-Bradley 1492-AIFM6TC-3 is a versatile analog I/O module from the 1492 Wiring System, designed specifically for thermocouple temperature inputs. It provides six channels, each with three terminals, enabling straightforward and secure connections.

Supporting a voltage range of 0 to 132 Volts AC/DC, this module accommodates diverse industrial sensing applications. Each circuit can handle up to 2 Amps, while the entire module supports a maximum of 12 Amps, ensuring robust performance under varying load conditions.

Compact in size and engineered for reliability, the 1492-AIFM6TC-3 operates efficiently within 0 to 60°C, making it suitable for standard industrial environments. Its modular design allows flexible integration into 1492 wiring chassis for precise and stable temperature measurement.

Technical Specifications

Key Features

• Six Thermocouple Inputs: Accurate temperature data acquisition for industrial applications.

• High Current Capacity: Supports up to 2 Amps per circuit and 12 Amps per module.

• Robust Voltage Range: Operates reliably between 0–132V AC/DC.

• Compact & Modular Design: Fits easily into 1492 wiring chassis for flexible installation.

• Temperature Resilient: Maintains stable operation from 0 to 60°C.

Applications

• Industrial temperature monitoring and control.

• Multi-channel thermocouple signal acquisition.

• Integration into 1492 Wiring System chassis for automation.

• Precise analog input applications in manufacturing processes.

FAQs

Q1: How many channels does the 1492-AIFM6TC-3 provide?
It offers six thermocouple input channels for temperature monitoring.

Q2: What voltage range is supported?
This module operates between 0 and 132 Volts AC/DC.

Q3: What is the maximum current per circuit?
Each circuit supports up to 2 Amps, with a total module capacity of 12 Amps.

Q4: What are the operating temperature limits?
It functions reliably within 0–60°C.

Q5: Is this module compatible with Allen-Bradley wiring systems?
Yes, it integrates with the 1492 Wiring System chassis.

Q6: Are these modules original and new?
All 1492-AIFM6TC-3 modules are factory-new, genuine Allen-Bradley products.

Q7: What is the shipping timeframe?
We ship within 3 days to 2 weeks, depending on order size, via DHL, FedEx, or UPS.

Q8: Can defective modules be returned?
We support returns within 30 days for defective or damaged units.
