Allen Bradley 1492-SP1C020 Miniature Circuit Breaker

Product Overview

The 1492-SP1C020 is a high-quality miniature circuit breaker from the Allen Bradley 1492 Wiring System, ideal for protecting circuits in industrial and commercial applications. Designed with a single-pole configuration, it provides reliable overcurrent protection with a 2 Amp current rating. This circuit breaker is capable of operating at a maximum voltage of 277 VAC (US) and 240 VAC (IEC), making it suitable for a range of electrical systems.

For enhanced safety, the 1492-SP1C020 features a True IP2X finger-safe design on the front of the unit, preventing accidental contact with live electrical parts. It complies with CE standards, ensuring it meets rigorous safety and quality regulations for use in a wide variety of environments.

The C Curve magnetic trip characteristic of the 1492-SP1C020 allows it to effectively handle inductive loads, offering dependable protection against overloads while maintaining stable operation under normal conditions. The DIN rail mounting ensures easy installation and secure placement in control panels, making this circuit breaker an excellent choice for demanding industrial applications.

Key Features

• Current Rating: 2 Amps, providing reliable protection for smaller circuits.

• Voltage Rating: Operates at 277 VAC (US) and 240 VAC (IEC) for flexibility across different regions.

• Pole Configuration: Single-pole design for compact and efficient circuit protection.

• Magnetic Trip Range: C Curve, ideal for inductive loads and preventing nuisance trips.

• Safety Features: True IP2X finger-safe design on the front face to prevent accidental contact with live parts.

• Certifications: CE marked, ensuring compliance with international safety standards.

• Mounting: DIN Rail, offering easy installation and secure mounting in control panels.

• Weight: 3.00 lbs (1.36 kg), lightweight for quick handling and integration.

Technical Specifications

Applications

• Electrical Protection: Ideal for industrial and commercial circuits that require reliable overcurrent protection.

• Inductive Load Control: Handles inductive loads effectively, making it suitable for motors and other inductive equipment.

• Control Panels: Perfect for use in control panels with DIN rail mounting, ensuring secure and efficient integration.

FAQ

Q1: What is the current rating of the 1492-SP1C020 circuit breaker?
A1: The 1492-SP1C020 is rated for 2 Amps, providing reliable protection for smaller circuits.

Q2: Is the 1492-SP1C020 suitable for use with inductive loads?
A2: Yes, the 1492-SP1C020 features a C Curve magnetic trip, making it ideal for inductive load applications.

Q3: What voltage ratings does the 1492-SP1C020 support?
A3: The 1492-SP1C020 operates at 277 VAC (US) and 240 VAC (IEC).

Q4: Does the 1492-SP1C020 have any safety features?
A4: Yes, it includes a True IP2X finger-safe design, ensuring safe operation by preventing accidental contact with live parts.

Q5: What is the mounting method for the 1492-SP1C020?
A5: The 1492-SP1C020 can be easily mounted on DIN rails, offering simple installation and secure integration.
