Allen Bradley 1492-SP1C100 Miniature Circuit Breaker

Product Overview

The 1492-SP1C100 from Allen Bradley is a highly reliable circuit breaker designed for use within the 1492 Wiring System. With a continuous current rating of 10 Amps, this model is perfect for protecting electrical circuits in various industrial and commercial applications. The C-Curve trip characteristic allows the breaker to handle inductive loads effectively, ensuring stable operation in systems involving motors and other inductive devices.

This circuit breaker operates at a maximum rated voltage of 480Y/277V AC (US) and 240V AC (IEC), offering versatility across different international standards. The interrupting capacity ranges from 5-10 kA (UL/CSA) and up to 15 kA (IEC), ensuring reliable protection against short circuits and overloads.

The 1492-SP1C100 is mounted on a DIN rail, making installation quick and secure. It also supports inductive loads, offering protection where electrical components like motors, transformers, or other inductive devices are involved.

Key Features

• Current Rating: 10 Amps for reliable protection of medium-sized circuits.

• Voltage Rating: Suitable for up to 480Y/277V AC (US) and 240V AC (IEC).

• Trip Curve: C-Curve, ideal for applications with inductive loads.

• Interrupting Capacity: 5-10 kA (UL/CSA), 15 kA (IEC), providing high protection in fault conditions.

• Mounting: DIN Rail mounting for easy and secure installation.

• Inductive Loads: Supports protection of circuits involving motors and other inductive loads.

• Weight: 3.00 lbs (1.36 kg) for easy handling and installation.

Technical Specifications

Applications

• Circuit Protection: Protects circuits from overloads and short circuits in both industrial and commercial settings.

• Inductive Loads: Ideal for circuits involving motors, transformers, and other inductive components.

• Control Panels: Perfect for use in DIN rail-mounted control panels, ensuring easy integration and efficient installation.

FAQ

Q1: What is the current rating of the 1492-SP1C100 circuit breaker?
A1: The 1492-SP1C100 has a continuous current rating of 10 Amps, making it suitable for medium-sized circuits.

Q2: What trip characteristic does the 1492-SP1C100 feature?
A2: The 1492-SP1C100 uses a C-Curve trip characteristic, ideal for protecting inductive loads such as motors and transformers.

Q3: What is the interrupting capacity of the 1492-SP1C100?
A3: The 1492-SP1C100 has an interrupting capacity of 5-10 kA (UL/CSA) and up to 15 kA (IEC), ensuring effective protection during fault conditions.

Q4: Is the 1492-SP1C100 suitable for inductive loads?
A4: Yes, the 1492-SP1C100 is specifically designed to support inductive loads, such as motors and transformers.

Q5: How is the 1492-SP1C100 mounted?
A5: The 1492-SP1C100 is mounted on a DIN rail, making installation quick and secure in control panels.
