Allen-Bradley 1715-TASOF8 Redundant I/O Termination Assembly

Overview

The Allen-Bradley 1715-TASOF8 is a high-quality termination assembly designed for the Bulletin 1715 Redundant I/O platform. It connects securely with the 1715-OF8I analog output module, offering robust wiring support and dependable signal transmission for industrial control systems. This module simplifies installation while maintaining excellent electrical isolation and long-term reliability.

Key Features

• Supports 8 simplex analog output channels for flexible control applications.

• Handles 0–24 mA per channel at 18–32 VDC, ensuring stable current output.

• Provides basic insulation and 50 V continuous isolation between ports and the backplane.

• Features conformal coating for enhanced durability in harsh environments.

• Offers DIN rail or panel mounting options for easy installation.

Technical Specifications

Installation Guidelines

Mount the 1715-TASOF8 module securely on a DIN rail or panel. Connect it to the 1715-OF8I through the 1715-A3IO base unit. Use a flathead screwdriver (0.4 × 2.0 mm) and tighten terminal screws to 0.5 N·m torque. Always use shielded wiring for EMC compliance and maintain proper cable routing for effective strain relief. Regularly inspect terminal tightness to ensure optimal connection integrity.

Environmental and Build Quality

The Allen-Bradley 1715-TASOF8 is built with a conformal-coated open-style enclosure that resists moisture and contaminants. It performs reliably across extreme temperatures and humidity levels, aligning with industrial standards such as ANSI/ISA-S71.04-2013 and IEC 60654-4:1987.

Applications

The 1715-TASOF8 is ideal for process automation, manufacturing, and energy management systems where redundant I/O reliability and precise analog output control are critical. It ensures stable communication and dependable power handling for long-term operational efficiency.

FAQs

Q1: Is the 1715-TASOF8 compatible with the 1715-OF8I analog module?
Yes, the 1715-TASOF8 directly interfaces with the 1715-OF8I via the 1715-A3IO base unit for seamless operation.

Q2: What wiring type is recommended for the 1715-TASOF8?
Use shielded copper wire rated at 85°C or higher, with a size between 22–16 AWG, to minimize interference.

Q3: Can the 1715-TASOF8 be mounted on a panel instead of a DIN rail?
Yes, it supports both DIN rail and panel mounting configurations.

Q4: What is the delivery and warranty policy?
All products are brand new and original. We have stock available, and orders typically ship within 3–14 days depending on size and logistics via DHL or other standard carriers. If any quality issue arises, returns are accepted within 30 days.
