Allen-Bradley 1715-TASOF8 Redundant I/O Termination Assembly Module

Overview

The Allen-Bradley 1715-TASOF8 is a termination assembly module designed for use with the Bulletin 1715 Redundant I/O system. It provides 8 analog output channels in a simplex configuration, offering reliable field wiring termination for the 1715-OF8I analog output module. This module is ideal for systems requiring robust and secure wiring termination, enhancing the performance and reliability of industrial automation setups.

Key Technical Specifications

Product Description

The 1715-TASOF8 termination assembly module ensures secure and reliable field wiring for the 1715-OF8I analog output module in Bulletin 1715 Redundant I/O systems. Designed for 8 analog outputs, this module offers a 0–24 mA output range with 18–32 VDC power supply, making it suitable for a wide range of industrial applications.

The module is built with shielded copper wire support and features basic insulation with a 50 V continuous isolation between the I/O ports and backplane. Its robust design ensures reliable performance in environments with high levels of vibration, humidity, and temperature variation.

Advantages

• 8 simplex analog output channels for flexible control in industrial systems.

• Reliable field wiring termination for the 1715-OF8I analog output module.

• Conformal coating ensures protection in harsh environments.

• Power dissipation of just 3.6 W, ensuring efficient operation.

• Vibration resistance (2 g @ 10–500 Hz) for demanding environments.

Installation and Maintenance

• Mounting: Supports DIN rail or panel mount installation.

• System Connection: Interfaces with the 1715-OF8I via 1715-A3IO base unit.

• Wiring: Shielded wiring is required for EMC compliance.

• Tools / Torque: Use a flathead screwdriver (0.4 × 2.0 mm) with a terminal screw torque of 0.5 N·m.

• Maintenance: Inspect terminal tightness and environmental sealing periodically.

FAQ

Q: How many analog output channels does the 1715-TASOF8 module support?
A: The 1715-TASOF8 supports 8 analog output channels in simplex configuration.

Q: What is the output range of the 1715-TASOF8 per channel?
A: Each output channel supports 0–24 mA at 18–32 VDC.

Q: What are the mounting options for the 1715-TASOF8 module?
A: The 1715-TASOF8 can be mounted on DIN rail or directly on a panel.

Q: What is the weight and size of the 1715-TASOF8 module?
A: The 1715-TASOF8 weighs 260 g and has dimensions of 132 × 42 mm.
