Allen-Bradley 1734-OB8S | POINT I/O Safety Output Module

Product Overview

The 1734-OB8S by Allen-Bradley is a POINT I/O Safety Output Module designed for GuardLogix and SmartGuard controllers. It features eight current sourcing outputs with a rated current of 1A per channel and a total aggregated current of 8A.

This module provides short-circuit detection, high reliability, and precise control in industrial safety applications. Its compact dimensions and lightweight design enable easy integration in control panels or distributed I/O networks.

Key Features

• Eight (8) current sourcing outputs per module

• 24V DC supply voltage, 1A per channel output current

• Supports dual-channel redundancy control

• Short-circuit protection with high, low, and cross-circuit detection

• Solid-state outputs with 475 μs pulse width and 575 ms pulse period

• Maximum field capacitance per output: 950 nF

• Compact size and lightweight: 3.03 × 0.98 × 2.17 in, 2.2 oz

• Status indicators for lock, power, and individual I/O channels

Technical Specifications

Installation & Safety

The 1734-OB8S module integrates easily into POINT I/O networks and supports dual-channel safety applications. Ensure proper wiring according to Allen-Bradley guidelines. Avoid exceeding maximum output current to maintain safe operation.

FAQ

Q1: Is this module factory new?
A1: Yes, the 1734-OB8S is fully original and factory new.

Q2: How fast is shipping?
A2: We ship in 3 days to 2 weeks depending on order size. DHL and other logistics options are available.

Q3: What if there is a quality issue?
A3: Returns are supported within 30 days for any quality problems.

Q4: What controllers are compatible with this module?
A4: The 1734-OB8S works with GuardLogix and SmartGuard controllers.

Q5: Can it handle short-circuits safely?
A5: Yes, the module provides electronic short-circuit protection and fault detection for high, low, and cross-circuit events.
