Allen-Bradley 1746-OVP16 | SLC 500 Digital DC Output Module

Product Overview

The 1746-OVP16 is an Allen-Bradley SLC 500 digital DC output module designed for high-current industrial applications. It provides 16 sinking outputs with individual LED indicators, enabling operators to monitor output status in real-time. The module includes fused common terminals and blown fuse LED alerts for enhanced safety. It simplifies creating custom automation solutions for various processes.

The 1746-OVP16 delivers fast signal responses of 60 milliseconds in and 2.5 milliseconds out. Each output can handle a continuous current of 1.5 amps with maximum surge current of 4A for 10 ms. The module supports reliable operations in clean, dry industrial environments between 0 and 60 °C.

Key Features

• 16 digital DC sinking outputs with LED indicators

• Voltage range: 20.4–26.4V DC sink

• Continuous current per output: 1.5A

• Maximum module current: 6.4A

• Fused common with blown fuse LED

• Fast step response: 60ms in, 2.5ms out

• Color-coded removable terminal blocks (RTBs)

• Radiated RF immunity: 10 V/m (30–2000 MHz), 1 V/m (2000–2700 MHz)

• Compact, robust design for industrial automation

Technical Specifications

Applications

The 1746-OVP16 module excels in high-current DC output applications. It integrates seamlessly with the SLC 500 system to control devices requiring reliable output switching. LED indicators and fused protection enhance safety and diagnostics in industrial environments.
