Allen-Bradley 1756-IB16ISOE | Sequence of Event Input Module

Overview

The 1756-IB16ISOE is a high-performance ControlLogix input module designed for precise event detection and sequence monitoring in industrial automation systems.

Technical Specifications

• Module Type: Digital DC Input

• Input Voltage Range: 10–30VDC

• Number of Inputs: 16 individually isolated channels

• Maximum Operating Current: 10 mA at 30VDC

• Isolation: Individually isolated inputs to prevent cross-channel interference

• Operating Temperature Range: -40°C to +70°C

• Compatibility: Integrates with ControlLogix communication interfaces for efficient data exchange

• Dimensions: Compact design for easy installation

• Weight: Lightweight, allowing flexible panel mounting

Features

• Each of the 16 inputs is individually isolated for reliable signal detection.

• Wide voltage range ensures compatibility with multiple industrial devices.

• Robust design supports long-term operation in extreme temperatures and harsh conditions.

• Integrates seamlessly with ControlLogix systems for fast, stable communication.

• Compact footprint simplifies panel installation and system expansion.

Applications

• Industrial automation requiring precise event logging and sequencing.

• Complex systems monitoring discrete input events across multiple channels.

• ControlLogix-based projects needing durable, high-performance input modules.

Benefits

The 1756-IB16ISOE enhances system reliability through precise timing and advanced isolation. Its durable construction reduces maintenance, improves uptime, and ensures accurate event recording across all industrial applications.
