Allen Bradley 1756-L63 ControlLogix Logix5563 Processor

Overview

The 1756-L63 from Allen-Bradley is a high-performance ControlLogix Logix5563 processor designed for complex industrial automation systems. It provides 8 MB of user memory, supporting applications with large data and multitasking requirements.

This processor supports up to 32 tasks with 100 programs per task, enabling extensive parallel processing. A dedicated RS-232 serial port ensures seamless communication with legacy devices, while compatibility with Ethernet/IP, ControlNet, DeviceNet, Data Highway Plus, Remote I/O, and SynchLink networks offers flexible connectivity.

With a compact size of 5.08 × 10.8 × 17.8 cm and a weight of only 0.99 lbs, the 1756-L63 fits standard DIN-rail mounted control panels. Power consumption is 2.5 W, and the processor operates reliably in temperatures from 0°C to 55°C and humidity ranges from 5% to 95% non-condensing.

The processor supports non-volatile memory of 128 MB and I/O memory of 478 KB. Battery compatibility with 1756-BA1 or 1756-BATM ensures real-time clock and memory retention. Its IP20 protection rating safeguards the internal electronics while maintaining accessibility for configuration and programming.

Key Features

• Brand: Allen-Bradley

• Model: 1756-L63

• Type: ControlLogix Logix5563 Processor

• User Memory: 8 MB

• I/O Memory: 478 KB

• Non-volatile Memory: 128 MB

• Tasks: 32 tasks, up to 100 programs per task

• Communication Ports: 1 RS-232 serial port

• Supported Networks: Ethernet/IP, ControlNet, DeviceNet, Data Highway Plus, Remote I/O, SynchLink

• Power Supply: 24V DC

• Power Consumption: 2.5 W

• Operating Temperature: 0°C to 55°C (32°F to 131°F)

• Relative Humidity: 5% to 95%, non-condensing

• Dimensions: 5.08 × 10.8 × 17.8 cm

• Weight: 0.99 lbs

• Mounting: DIN Rail

• Protection Rating: IP20

• Battery: Compatible with 1756-BA1 or 1756-BATM

• Origin: USA

Technical Specifications

Advantages

• High-performance ControlLogix processor for demanding automation tasks

• 8 MB user memory accommodates large programs and complex logic

• Supports 32 multitasking operations with 100 programs per task

• RS-232 port ensures connectivity with legacy devices

• Compatible with multiple industrial networks for versatile integration

• Compact DIN-rail design saves space and simplifies installation

• Reliable operation under wide temperature and humidity ranges

• IP20 protection safeguards electronics while maintaining accessibility
