Allen-Bradley 1756-OB8 | ControlLogix DC Output Module

Product Overview

The Allen-Bradley 1756-OB8 ControlLogix DC Output Module provides reliable and precise control for demanding industrial automation systems. With eight 24V DC outputs, each rated at 3 Amps, it delivers the performance needed for controlling a wide variety of field devices.

Designed for seamless integration with ControlLogix systems, the 1756-OB8 communicates efficiently through the ControlLogix bus and ensures quick configuration. Its compact chassis-based design allows easy installation and secure mounting, saving time during setup.

Engineered to perform under harsh environmental conditions, this module operates within a wide -40°C to +70°C temperature range. The advanced 200V AC isolation between channels enhances reliability and protects equipment against electrical interference.

Key Features

• Provides 8 DC output channels, each supporting up to 3 Amps.

• Rated for 24V DC output voltage with dependable current delivery.

• Operates in environments from -40°C to +70°C, ensuring durability.

• Incorporates 200V AC isolation for safe and stable operation.

• Built with robust materials for extended service life.

• Designed for easy installation on a ControlLogix chassis.

Technical Specifications

Application

The Allen-Bradley 1756-OB8 module is ideal for machine builders and process industries requiring dependable digital output control. With its rugged design, high isolation, and strong current handling, it ensures smooth operation in critical applications such as material handling, packaging, and process automation.

FAQ

Q1: Is the Allen-Bradley 1756-OB8 brand new and original?
A1: Yes, we only supply brand-new, factory-sealed products.

Q2: Do you have the 1756-OB8 in stock?
A2: Yes, we maintain stock. Orders typically ship within 3 days to 2 weeks depending on size.

Q3: Which couriers are available for delivery?
A3: We usually ship with DHL, UPS, or FedEx for reliable and fast delivery.

Q4: What if the 1756-OB8 has a quality issue?
A4: We support returns within 30 days if any product quality issue arises.

Q5: What is the maximum current rating per output channel?
A5: Each of the 8 DC outputs on the 1756-OB8 supports up to 3 Amps.
