Allen-Bradley 1756HP-GPS | ControlLogix Bus Receiver Module

Overview

The Allen-Bradley 1756HP-GPS is a GPS receiver module that ensures precise time synchronization and position accuracy for automation systems. By integrating GPS technology, it delivers accurate time stamping and seamless coordination across ControlLogix platforms, making it suitable for industrial automation, asset tracking, and synchronized operations.

Technical Specifications

The 1756HP-GPS operates on the GPS L1 band and communicates using the NMEA 0183 protocol. Its accuracy reaches within 10 meters under ideal conditions, while response time remains below five seconds. With a power consumption of less than 2.5 Watts, the module ensures efficient energy use.

Physical Dimensions and Build

Measuring 3.8 cm x 12.7 cm x 18.4 cm (1.5 in x 5.0 in x 7.3 in) and weighing just 0.50 lbs, the 1756HP-GPS offers a compact and lightweight design. Its IP67 rating guarantees dustproof and waterproof protection, enabling reliable operation even in demanding industrial environments.

Environmental and Operational Data

The 1756HP-GPS supports a wide temperature range from -40 °C to +85 °C (-40 °F to +185 °F). This rugged tolerance ensures stable performance in both extreme cold and high-heat conditions. Its panel-mounting design simplifies installation, providing engineers with flexibility in diverse system layouts.

Application Benefits

By delivering precise GPS-based time synchronization, the 1756HP-GPS enhances system reliability and data integrity. It improves coordination among distributed devices and ensures accurate logging for event-driven applications. The combination of compact size, low power usage, and robust construction makes it a dependable choice for industrial automation.
