Allen-Bradley 1762-L40BWAR | MicroLogix Relay Module

Overview

The 1762-L40BWAR MicroLogix Relay Module from Allen-Bradley provides reliable control and monitoring for industrial automation systems. It features 20 standard 24VDC inputs and 16 relay outputs, ensuring precise and efficient signal management. Its compact design allows seamless integration into existing MicroLogix setups, streamlining your automation processes.

Equipped with multiple communication ports, including embedded 8-pin mini-DIN supporting DF1, DH-485, ASCII, and MODBUS protocols, the 1762-L40BWAR enables versatile connectivity with a wide range of devices. Users can program the module via the left-side programming port, supporting flexible ladder logic configurations for customized control applications.

The module operates reliably across diverse voltages, supporting 5–265V AC and 5–125V DC, while its relay contacts handle 24–125VDC and 120–240VAC circuits. Advanced technology ensures fast response and durable performance even under demanding industrial conditions.

Key Features

• Brand: Allen-Bradley

• Model: 1762-L40BWAR

• Type: MicroLogix Relay Module

• Standard Inputs: 20 × 24VDC

• Fast Inputs: 4 × 24VDC

• Relay Outputs: 16

• Communication Ports: Embedded 8-pin mini-DIN (DF1, DH-485, ASCII, MODBUS)

• Programming Port: Left side of the module

• Operating Voltage Range: 5–265V AC; 5–125V DC

• Contact Voltage Ratings: 24–125 VDC; 120–240VAC

• Performance Lab Tested: Yokogawa Temperature Controller UT55A-201-11-00

• Certifications: RoHS/WEEE

• Compatibility: PROFIBUS-DP, CC-Link, DeviceNet

Technical Specifications

Advantages

• Offers fast and reliable relay switching for industrial applications

• Multiple communication ports ensure seamless connectivity

• Supports diverse voltage ranges for AC and DC circuits

• Compact size allows easy integration into existing systems

• Ladder logic programming simplifies control customization

FAQ

Q1: Is the Allen-Bradley 1762-L40BWAR brand new?
A1: Yes, it is fully original, factory-sealed, and brand new.

Q2: How soon can you ship this module?
A2: We ship within 3 days to 2 weeks depending on order size and logistics, commonly via DHL.

Q3: What voltage range does the 1762-L40BWAR support?
A3: It operates with 5–265V AC and 5–125V DC, compatible with AC and DC circuits.

Q4: How many relay outputs does this module have?
A4: The module provides 16 relay outputs for reliable control.

Q5: Which communication protocols are supported?
A5: It supports DF1, DH-485, ASCII, and MODBUS via the embedded 8-pin mini-DIN port.

Q6: Do you accept returns for defective units?
A6: Yes, we support returns within 30 days if there are any quality issues.
