Allen-Bradley 1762sc-IF8U | Universal Analog Input Module

Specifications

  • Manufacturer: Allen Bradley

  • Product No.: 1762SC-IF8U

  • Condition： 10 Items in Stock

  • Product Type: Analog Input Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 450g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product details

Description

Product Overview

The 1762sc-IF8U by Spectrum Controls, an Allen-Bradley Encompass partner, is an 8-channel universal analog input module. It supports voltage, current, thermocouple, or RTD signals, providing flexible measurement options for MicroLogix 1762 series controllers.

It operates efficiently in industrial environments, withstanding temperatures up to 60°C, vibrations from 10 to 500 Hz, and altitudes up to 2000 meters. The module features DIN rail or mounting plate installation for optimal space utilization and proper ventilation.

Key Features

  • 8 universal analog input channels

  • Supports voltage, current, thermocouple, and RTD/resistance signals

  • Up to 4 RTD or resistance channels (2, 3, or 4-wire configuration)

  • Voltage input ranges: ±50 mV, ±100 mV, 0–5V, 1–5V, ±10V, 0–10V

  • Current input ranges: 0–20 mA, 4–20 mA

  • Thermocouple types: J, K, T, B, E, R, S, N, C

  • RTD sensor compatibility with multiple Pt, Cu, and Ni types

  • 16-bit resolution with selectable input filters: 4, 17, 62, 470 Hz

  • Channel update times: 495, 135, 45, 20 ms

Technical Specifications

Specification Details
Manufacturer Spectrum Controls / Allen-Bradley
Model 1762sc-IF8U
Series 1762 MicroLogix
Product Type Universal Analog Input Module
Channels 8
RTD/Resistance Channels Up to 4 (2, 3, or 4-wire)
Input Types Voltage, Current, Thermocouple, RTD/Resistance
Voltage Input Ranges ±50 mV, ±100 mV, 0–5V, 1–5V, ±10V, 0–10V
Current Input Ranges 0–20 mA, 4–20 mA
RTD Compatibility Pt 100/200/500/1000, Cu 10, Ni 100/120, NiFe 604
Thermocouple Types J, K, T, B, E, R, S, N, C
Resolution 16 Bits
Input Filters 4, 17, 62, 470 Hz
Channel Update Time 495, 135, 45, 20 ms
Thermal Dissipation 1.4 W max
Mounting DIN rail or mounting plate
Max Operating Temperature 60°C
Vibration 10–500 Hz
Max Altitude 2000 m

Installation & Wiring

Install the 1762sc-IF8U close to input devices to maximize measurement accuracy. Use shielded, twisted-pair TC wires for thermocouples and Belden 8761 or equivalent for RTD, mV, V, or mA signals. Maintain proper grounding to minimize electromagnetic interference.

FAQ

Q1: Is the module factory new?
A1: Yes, the 1762sc-IF8U is fully original and factory new.

Q2: What is the shipping time?
A2: We ship in 3 days to 2 weeks depending on order size. DHL and other logistics are available.

Q3: How many channels can handle RTD inputs?
A3: Up to 4 channels can be configured for RTD or resistance inputs.

Q4: Which input signals are compatible?
A4: The module supports voltage, current, thermocouple (J, K, T, B, E, R, S, N, C), and RTD/resistance.

Q5: What mounting options are available?
A5: Mount the 1762sc-IF8U on a DIN rail or a mounting plate with proper ventilation.
