Allen-Bradley 1763-L16DWD | MicroLogix 1100 Programmable Controller

Product Overview

The 1763-L16DWD is an Allen-Bradley MicroLogix 1100 programmable controller designed for DC-powered industrial automation. It delivers 16 integrated I/O points for versatile control applications, including discrete, analog, and relay outputs.

This controller operates on a 12–24V DC input and supports high-speed and standard discrete inputs. It provides two 0–10V DC analog inputs compatible with 2-wire, 3-wire, or 4-wire transmitters. Communication is facilitated through one Ethernet port and one RS-232/RS-485 port. The built-in LCD enables clear status monitoring and local diagnostics.

The 1763-L16DWD is compact and lightweight at just 1.31 lbs (0.60 kg). It supports reliable industrial operations with integrated I/O and communication options suitable for medium-density control applications.

Technical Specifications

Features and Benefits

• Versatile I/O: Sixteen integrated points with both digital and analog support.

• High-Speed Inputs: Four high-speed digital channels for precise process monitoring.

• Reliable Analog Support: Two 0–10V analog inputs compatible with various transmitter types.

• Flexible Communication: Ethernet and RS-232/485 ports allow seamless integration with PLCs.

• Compact & Lightweight: 1.31 lbs for easy installation in tight control panels.

Applications

• Small to medium industrial automation projects.

• Data acquisition and process control using MicroLogix 1100 I/O.

• Integration with sensors, actuators, and relay-controlled devices.

• Remote monitoring and control via Ethernet or serial communication.

FAQ

Q1: How many I/O points does the 1763-L16DWD support?
It supports a total of 16 I/O points, including digital, analog, and relay outputs.

Q2: What type of analog inputs does this controller provide?
It has two 0–10V DC analog input channels, suitable for 2-wire, 3-wire, or 4-wire transmitters.

Q3: Which communication ports are available?
The controller provides one Ethernet port and one RS-232/RS-485 port.

Q4: What is the input voltage range?
The 1763-L16DWD operates on 12–24V DC input.

Q5: Can this controller be mounted in compact panels?
Yes, its lightweight 1.31 lbs design allows installation in tight or compact control panels.
