AB 1764-28BXB – Programmable Logic Controller

Overview

The AB 1764-28BXB MicroLogix 1500 Base is a compact and robust programmable logic controller (PLC) designed for industrial automation applications. Equipped with 16 24VDC inputs, it offers precise control and reliable performance even in demanding environments. Its versatile communication interfaces ensure seamless integration into existing automation networks.

Key Features

• 16 discrete 24VDC inputs for comprehensive monitoring and control.

• Rugged design with high resistance to shock and vibration for industrial environments.

• Supports Ethernet/IP and serial communication for networked and legacy system integration.

• Compact form factor for panel or DIN rail mounting.

• User-friendly configuration and setup for streamlined deployment.

Technical Specifications

• Model: 1764-28BXB

• Technology: MicroLogix 1500

• Power Supply: 24VDC

• Number of Inputs: 16, 24VDC

• Dimensions: Width 90 mm × Height 87 mm × Depth 180 mm

• Operating Temperature: -20°C to 60°C

• Humidity: 5% – 95% non-condensing

• Vibration Resistance: 3 G at 10–500 Hz

• Shock Resistance: Operating: 30 G; Non-operating: Panel Mount 50 G, DIN Rail 40 G

• Communication Interfaces: Ethernet/IP, Serial

• Installation: Panel or DIN rail mount

The AB 1764-28BXB is engineered for reliable operation, flexibility, and seamless integration, making it an ideal PLC solution for industrial automation systems requiring precise control and monitoring.
