Allen-Bradley 1768-ENBT | CompactLogix Ethernet Communication Module

Product Overview

The 1768-ENBT is a high-performance Ethernet communication module from Allen-Bradley. It connects CompactLogix controllers to Ethernet networks with fast and reliable communication. This module enables seamless integration with HMIs, SCADA systems, and other PLCs.

The module measures 279 × 318 × 146 mm and weighs 1.2 kg. You can mount it on a DIN rail or panel for flexible installation. It simplifies network configuration and supports multiple topologies, ensuring adaptability to various industrial environments.

Technical Specifications

• Communication Protocol: Ethernet/IP

• Speed: 10/100 Mbps with auto-negotiation

• Connections: Up to 64 Logix (CIP) connections and 32 TCP/IP connections

• Mounting: DIN rail or panel mount

• Indicators: Status LEDs for monitoring module activity

• Configuration: Programmed and managed via the controller’s software

• Network Support: CIP standard, multiple topologies

• Origin: USA

• Warranty: 12 months

Key Features

• High-Speed Communication: Achieves fast data transfer for efficient monitoring and control.

• Flexible Topologies: Supports different network layouts to fit complex automation systems.

• Reliable Connection: Maintains stable performance for critical time-sensitive tasks.

• Easy Integration: Simplifies setup using the controller’s programming software interface.

Applications

The 1768-ENBT module suits a wide range of industrial automation applications:

• Plant management and monitoring

• Time-critical operations without fixed schedules

• High-speed data collection and transmission

• Internet and intranet connectivity

• System configuration and real-time control
