Allen-Bradley 1769-OV32T | 24V DC Sink Output Module

Product Overview

The 1769-OV32T by Allen-Bradley is a 24V DC sink output module engineered for high-reliability control applications in industrial automation. This module provides sixteen output channels with 32mA per channel and up to 1A load capability, allowing precise control of relays, solenoids, and other devices.

Its compact dimensions and robust design enable seamless integration into existing systems, reducing installation time and minimizing operational downtime. The module supports two-wire RS-485 communication, enhancing system efficiency and simplifying wiring complexity.

Key Features

• 16-channel 24V DC sink output module

• 32mA per channel with up to 1A load capability

• Supports ControlNet and RS-485 communication interface

• Compact dimensions: 127×76.2×35 mm

• Low power consumption, typically <1W

• IP20 enclosure for reliable industrial operation

• Certified UL, CE, ISO 9001 compliance

Technical Specifications

Installation & Integration

The 1769-OV32T easily integrates into industrial automation systems. Its sixteen-channel design allows direct connection to devices requiring current sourcing without additional hardware. Compact size and IP20 enclosure support DIN rail or panel mounting in tight control cabinets.

FAQ

Q1: Is this module factory new?
A1: Yes, the 1769-OV32T is fully original and factory new.

Q2: How fast is shipping?
A2: We ship in 3 days to 2 weeks depending on order size. DHL and other logistics options are available.

Q3: What if there is a quality issue?
A3: We support returns within 30 days for any quality problems.

Q4: Can it drive relays or solenoids directly?
A4: Yes, each channel supports sink current output up to 1A, suitable for direct connection to relays or solenoids.

Q5: Which communication interfaces are supported?
A5: The module supports ControlNet and two-wire RS-485 communication for seamless integration.
