Allen-Bradley 1771-ICD | Industrial Control Module

Product Overview

Allen-Bradley 1771-ICD 1771ICD Control Module

The Allen-Bradley 1771-ICD 1771ICD is a high-performance industrial control module engineered for complex automation environments. It integrates seamlessly with Allen-Bradley PLC backplanes, delivering reliable performance across diverse applications.

Technical Specifications

This module features 32 input/output channels, an input current rating of 280mA, and an operating voltage of 220V. It supports a frequency response up to 30kHz, ensuring fast signal processing for demanding control tasks. With dimensions of 3.2 x 15.8 x 27cm and a weight of 0.5kg, it offers a compact yet durable form factor.

Connectivity and Integration

The Allen-Bradley 1771-ICD 1771ICD comes with built-in Ethernet and RS-485 interfaces, enabling real-time communication and efficient remote control. Its versatile design supports both digital and analog signal types, making it suitable for manufacturing, process automation, and equipment monitoring.

Capacity and Control

This module can handle up to 128 inputs and includes 16 discrete output relays, providing broad monitoring and automation flexibility. Its low power consumption minimizes system energy load while maintaining consistent performance.

Reliability and Application

The Allen-Bradley 1771-ICD 1771ICD is built for long-term reliability, tested to meet strict industry standards. Its panel mount design allows easy installation without extensive modifications, and its wide operating temperature range ensures stable performance in harsh environments.
