Allen-Bradley 1771-NT2 | PLC-5 Thermocouple Input Module

Product Overview

The Allen-Bradley 1771-NT2 is an N-Series Analog Input Module designed for the PLC-5 family. With 8 input channels supporting thermocouple and millivolt signals, this module ensures accurate measurement across a wide temperature range. It delivers a 16-bit resolution with 0.01% typical accuracy, making it ideal for demanding process control applications.

This module offers an input bandwidth of 9 Hertz and a maximum update time of 25 milliseconds, ensuring fast and reliable performance. At only 1.75 lbs (0.79 kg), the 1771-NT2 combines durability with compact rack-mountable installation.

Key Specifications for 1771-NT2

Features and Benefits

• The 1771-NT2 supports multiple thermocouple types (B, R, S, E, J, K, T, C, N).

• Each input channel can be configured independently to match application needs.

• It offers programmable reset values, allowing flexible operation in complex systems.

• High resolution and fast update times ensure reliable data acquisition.

• Designed for rack mounting with the 1771-WH wiring arm, providing easy integration.

Applications

The Allen-Bradley 1771-NT2 is widely used in industries requiring high-accuracy temperature measurement, including chemical plants, food processing, and energy systems. Its high resolution and stability make it ideal for critical process automation tasks.

FAQ

Q1: What type of signals does the 1771-NT2 support?
It supports thermocouple signals (Types B, R, S, E, J, K, T, C, N) and direct millivolt inputs.

Q2: What is the resolution of the 1771-NT2 module?
The module provides 16-bit resolution with 0.01% typical accuracy.

Q3: What is the recommended wiring arm for this module?
The 1771-WH wiring arm is required for proper installation.

Q4: Do you have stock for the 1771-NT2?
Yes, we stock brand new original modules. Delivery is available within 3 days to 2 weeks, depending on order size.

Q5: What if the module has a quality issue?
We support returns within 30 days if any quality issues occur.

Q6: Which shipping methods are available?
We usually ship with DHL, FedEx, or UPS to ensure fast and secure delivery.
