Allen-Bradley 1784-PCM5 | DH+ Communication Cable

Product Overview

The Allen-Bradley 1784-PCM5 is a DH+ communication cable designed for industrial automation networks. It enables stable connections between computers equipped with a 1784-PCMK/B card and controllers such as the PLC-2, PLC-3, or PLC-5 processors. The cable also works with enhanced PLC-5 processors, providing reliable data transfer at 230 kbps.

This cable includes two wedges and a 1784-CP7 adapter that reinforce the connection to the computer, ensuring durability in demanding environments. Weighing only 0.50 lbs, the 1784-PCM5 offers lightweight handling without compromising ruggedness.

Key Technical Specifications

Features and Benefits

• The 1784-PCM5 cable supports direct connectivity to PLC-2, PLC-3, and PLC-5 processors.

• At 230 kbps, it ensures efficient and reliable Data Highway Plus (DH+) network communication.

• The included wedges and 1784-CP7 adapter improve stability for PCMCIA card connections.

• Its compact weight of 0.50 lbs allows easy transport while maintaining robust build quality.

• Engineers can perform loopback diagnostic tests by linking the 1784-PCM5 to the 1784-PCMK card.

Application Use Cases

The Allen-Bradley 1784-PCM5 is commonly used in automation setups that require communication between laptops with 1784-PCMK/B cards and legacy controllers such as PLC-5 processors. It is essential for system configuration, troubleshooting, and diagnostics in industrial environments.

FAQ

Q1: Is the Allen-Bradley 1784-PCM5 cable new and original?
Yes, we only supply 100% brand new and original 1784-PCM5 cables from Allen-Bradley.

Q2: Do you have this cable in stock?
We maintain stock for 1784-PCM5, and shipping takes 3 days to 2 weeks depending on order size.

Q3: Which processors are supported by the 1784-PCM5?
It works with PLC-2, PLC-3, and PLC-5 processors, including enhanced PLC-5 units.

Q4: Can the 1784-PCM5 perform a loopback test?
Yes, but you must connect it to the 1784-PCMK card and ensure it is not linked to a DH+ network.

Q5: What shipping options do you provide?
We typically ship using DHL, UPS, or FedEx for fast and secure global delivery.

Q6: What is your return policy if there are problems?
If the 1784-PCM5 has any quality issues, we accept returns within 30 days.
