Allen-Bradley 1794-IE8XOE4 | FLEX I/O Analog Module

Product Overview

The 1794-IE8XOE4 is an Allen-Bradley high-density FLEX I/O analog module designed for modular automation systems. It connects to a terminal base and an adapter or power supply to provide reliable analog input and output capabilities.

This module allows adjustable voltage between 0 and 10 Volts DC and supports current from 0 to 20 mA. It is ideal for applications requiring precise analog signal control in distributed or rack-based I/O systems.

Equipped with 8 single-ended inputs and 4 outputs, the 1794-IE8XOE4 efficiently integrates into FLEX I/O systems while supporting BTW and BTR instruction sets for flexible programming.

Technical Specifications

Features and Benefits

• High-Density Analog I/O: 8 inputs and 4 outputs in a compact module design.

• Adjustable Voltage & Current: Supports fine-tuning from 0–10V and 0–20 mA.

• Modular FLEX I/O Integration: Connects seamlessly to terminal bases and adapters.

• Single-Ended, Non-Isolated Design: Simplifies installation while maintaining accurate signal processing.

• Programmable with BTW and BTR: Offers flexible programming for analog control applications.

Applications

• Industrial automation requiring precise analog signal control.

• Distributed I/O or rack-based FLEX I/O systems.

• Process monitoring, measurement, and control.

• Signal conditioning for sensors and actuators.

FAQ

Q1: How many inputs and outputs does the 1794-IE8XOE4 have?
It features 8 single-ended inputs and 4 analog outputs.

Q2: What is the voltage and current range for this module?
Voltage is adjustable between 0–10V DC and current between 0–20 mA.

Q3: Which instruction sets are supported?
The module supports BTW and BTR instructions for flexible programming.

Q4: What is the weight of the module?
The 1794-IE8XOE4 weighs 0.25 lbs (0.11 kg).

Q5: How is this module integrated into FLEX I/O systems?
It connects to a terminal base and an adapter or power supply for full system integration.
