Allen-Bradley 1797-IBN16 | 16-Point Digital Input Module

Product Overview

The 1797-IBN16 Input Module from Allen-Bradley delivers high-performance digital signal acquisition for industrial control systems. This 16-point module ensures accurate and reliable data processing in demanding environments.

Its compact design mounts easily on a DIN rail, minimizing space requirements while supporting quick installation and maintenance. The 1797-IBN16 operates with low current consumption of less than 20 mA and achieves response times under 10 milliseconds, enhancing energy efficiency and system responsiveness.

Built for extreme conditions, the module operates across a wide temperature range of -40°C to +85°C and tolerates non-condensing humidity from 5% to 95%. Its IP20-rated enclosure protects internal circuitry while maintaining compact dimensions of 115 mm × 102 mm × 97 mm and a lightweight design of approximately 150 g.

Advanced diagnostic indicators provide real-time status feedback, allowing operators to implement proactive maintenance schedules and ensure continuous system uptime. The 1797-IBN16 integrates seamlessly with leading industrial controllers, offering engineers a reliable and cost-effective solution for automation projects.

Key Features

• High-performance 16-point digital input module

• Operating voltage: 24 VDC with <20 mA current consumption

• Response time: Less than 10 milliseconds

• DIN rail mountable for compact installation

• Enclosure rating: IP20, suitable for industrial environments

• Operating temperature: -40°C to +85°C

• Relative humidity: 5% to 95% non-condensing

• Advanced diagnostics with real-time status feedback

• Lightweight: 150 g, Dimensions: 115 × 102 × 97 mm

Technical Specifications

Applications

The 1797-IBN16 is ideal for industrial automation tasks requiring reliable signal acquisition, such as manufacturing processes, chemical plants, water treatment, and other automated control systems. Its robust design ensures consistent performance in harsh environmental conditions.

FAQ

Q1: Is the 1797-IBN16 fully original and new?
A: Yes, the 1797-IBN16 is 100% new and original from Allen-Bradley.

Q2: What is the maximum response time of this module?
A: The 1797-IBN16 achieves a response time of less than 10 milliseconds.

Q3: How is it mounted?
A: The module mounts directly on a DIN rail for easy installation and maintenance.

Q4: What operating temperatures can it handle?
A: The 1797-IBN16 functions from -40°C to +85°C.

Q5: How quickly can the product ship?
A: Stock is available. Orders ship within 3 days to 2 weeks depending on size, typically via DHL or other common carriers.
