Allen-Bradley 2094-BC02-M02-S Kinetix 6000 Integrated Axis Module
Specifications
Manufacturer: Allen Bradley
Product No.: 2094-BC02-M02
Condition： 10 Items in Stock
Product Type: Integrated Axis Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 1700g
Shipping port: Xiamen
Warranty: 12 months
Product details
Description
Overview
The Allen-Bradley 2094-BC02-M02-S is an advanced Integrated Axis Module (IAM) from the Kinetix 6000 series, designed for industrial automation and control. With a high efficiency of 97%, this 400VAC class module ensures seamless operation in demanding environments. It features precise power handling capabilities, robust construction, and outstanding reliability, making it ideal for automation applications requiring high-speed control and performance.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Model Number | 2094-BC02-M02-S |
| Product Line | Kinetix 6000 |
| Module Type | IAM (Integrated Axis Module) |
| AC Input Voltage | 324–528 Volts RMS (Nominal 360–480V) |
| AC Input Current (Nominal RMS) | 24.0 Amps |
| Maximum Inrush Current (0-peak) | 22.0 Amps |
| AC Input Frequency | 47–63 Hertz |
| DC Input Voltage | 458–747 VDC |
| DC Input Current (Common Bus Follower) | 22.6 Amps |
| Control Power AC Input Voltage | 95–264 Volts RMS |
| Control Power AC Input Current | 0.9 Amps |
| Efficiency | 97% |
| Weight | 16.00 lbs (7.26 kg) |
| Internal Shunt Resistor | 115 Ohms |
| Internal Shunt (Continuous Power) | 50 Watts |
| Internal Shunt (Peak Power) | 5.6 Kilowatts |
| Operating Temperature | -10°C to +60°C |
| Operating Altitude | Up to 2000 meters |
Description
The Allen-Bradley 2094-BC02-M02-S Integrated Axis Module (IAM) integrates seamlessly with Kinetix 6000 systems, offering reliable and precise motion control in industrial applications. It is built to withstand harsh conditions with a wide input voltage range of 324–528VAC, and a nominal value of 360–480V for the AC input. With an efficiency of 97%, this module operates reliably under a variety of conditions.
The module offers both high DC input voltage of 458–747 VDC and AC input voltage for superior energy efficiency, while the maximum inrush current is limited to 22.0 Amps. It also supports a control power AC input voltage of 95–264 Volts RMS, ensuring compatibility with a broad range of systems.
Applications
Ideal for motion control, automation systems, and precision machinery, the 2094-BC02-M02-S is perfect for systems requiring high-performance, reliable, and energy-efficient solutions. It supports various AC and DC inputs and has been engineered to deliver the utmost in speed and accuracy.
FAQ
Q1: What is the input voltage range for the Allen-Bradley 2094-BC02-M02-S?
A1: The input voltage range for the 2094-BC02-M02-S is 324–528 Volts RMS for AC input, with a nominal value of 360–480V. The DC input voltage range is 458–747 VDC.
Q2: What is the efficiency of this module?
A2: The 2094-BC02-M02-S offers an impressive 97% efficiency, ensuring minimal energy loss during operation.
Q3: What is the inrush current of this module?
A3: The maximum inrush current is 22.0 Amps (0-peak), ensuring safe and controlled startup.
Q4: How long will it take to ship the Allen-Bradley 2094-BC02-M02-S?
A4: Depending on the order size, we typically ship within 3 days to 2 weeks. Common shipping options include DHL and other reliable services.
Q5: Do you offer returns if there are quality issues?
A5: Yes, we offer a 30-day return policy for quality-related issues on the 2094-BC02-M02-S module.
