Allen-Bradley 2094-BC04-M03-M Kinetix 6000 Axis Module

Product Overview

The 2094-BC04-M03-M from Allen-Bradley is a Kinetix 6000 Integrated Axis Module designed for high-performance multi-axis servo drive applications. It delivers continuous power to the bus of 13.5 kW and supports a continuous output current of 21.2 A, ensuring reliable industrial automation performance.

This axis module operates on an AC input voltage range of 360–480 V, 3-phase, with a nominal bus voltage of 650 VDC. It provides a peak current rating of 53 A (rms) and 75 A (0-pk) for dynamic motor loads, maintaining robust performance in demanding applications.

With a velocity loop bandwidth of 500 Hz and a current loop bandwidth of 1300 Hz, the 2094-BC04-M03-M enables precise motion control. The PWM frequency of 4 kHz ensures smooth and accurate motor actuation. Its 98% efficiency, along with 840 µF bus capacitance and 108 Joules capacitive energy absorption, provides energy-efficient operation.

Constructed with durable materials, the module withstands industrial environments and features a short-circuit rating of 200,000 A (rms) symmetrical. Installation is facilitated with minimum enclosure depth of 272 mm and 50.8 mm installation clearance.

Technical Specifications

Key Features

• Delivers 13.5 kW continuous power with high current capacity for demanding servo drives.

• Integrates into Kinetix 6000 multi-axis drive systems seamlessly.

• Provides precise motion with 500 Hz velocity loop and 1300 Hz current loop.

• Operates with 360–480 V AC, 3-phase input for versatile industrial environments.

• Built with robust materials for long-term reliability and high short-circuit tolerance.

Typical Applications

• Multi-axis servo drive automation systems.

• Industrial motion control requiring precise motor management.

• Integration into Kinetix 6000 drives for manufacturing and production lines.

• High-efficiency, energy-conscious industrial automation setups.
