Allen-Bradley 2198-P141 | DC-Bus Power Supply Module

Overview

The Allen-Bradley 2198-P141 is a high-performance DC-bus power supply for Kinetix 5700 servo drives. It supports three-phase AC input voltage from 324–524 V RMS (480 V nominal) at 47–63 Hz, enabling consistent operation in industrial environments.

This module delivers a continuous output power of 31 kW with 1640 µF internal capacitance and 362 J of capacitive energy absorption. Its 22–40 lb*in (2.5–4.5 N·m) torque range allows precise control of high-performance servo motors.

Designed with a snap-fit installation system, the 2198-P141 requires no tools, simplifying integration into machine control panels. A single drive can accommodate up to three modules to increase total output capacity.

Key Technical Specifications

Features and Advantages

• High-efficiency design with 99% energy conversion and minimal power loss.

• Compact and robust construction for machines with large axis counts.

• Supports up to three modules per drive for scalable power requirements.

• Integrated motion and safety features over EtherNet/IP simplify system control.

• 1640 µF internal capacitance and 362 J energy absorption enable stable power delivery.

• Easy snap-fit installation reduces integration time and maintenance effort.

FAQ

Q1: Is the Allen-Bradley 2198-P141 new and original?
Yes, all units are fully new, factory-sealed, and original Allen-Bradley modules.

Q2: How many modules can one Kinetix 5700 drive support?
A single Kinetix 5700 drive supports up to three 2198-P141 modules.

Q3: What is the continuous output power of this module?
The 2198-P141 provides 31 kW continuous output to the servo drive bus.

Q4: What is the AC input range?
It accepts 324–524 V AC RMS, three-phase, at 47–63 Hz.

Q5: How does installation work?
The module features a snap-fit system that requires no tools, simplifying mounting.

Q6: What applications is it suitable for?
Ideal for machines with high axis counts, including beverage machines, tire builders, tray loaders, and bag machines.
