Allen-Bradley 22B-D012N104 PowerFlex 40 AC Drive

Product Overview

The Allen-Bradley 22B-D012N104 is a PowerFlex 40 Adjustable Frequency AC Drive, engineered to control AC motor speed efficiently while reducing energy consumption. It delivers an output power of 5.5 kW (7.5 HP) with a maximum current of 12.0 Amperes.

This drive operates with a three-phase supply voltage ranging from 342-528 VAC, ensuring compatibility with industrial power systems. It features an intuitive keypad interface and RS-485 communication, enabling convenient local control and integration with automation networks.

Designed for panel mounting, the 22B-D012N104 utilizes an IP20/NEMA open-type enclosure. The unit includes a brake and requires proper external protection such as circuit breakers or fuses for safe operation. The drive supports variable frequency and speed control, providing optimized motor performance and energy efficiency.

Technical Specifications

Key Features

• Precise Motor Control: Adjustable frequency provides accurate AC motor speed regulation.

• Energy Efficiency: Optimizes power consumption while maintaining performance.

• Robust Communication: RS-485 enables integration with industrial control networks.

• User-Friendly Interface: Keypad allows simple local operation and parameter adjustments.

• Compact Design: Panel-mountable IP20 enclosure saves space in control panels.

• Integrated Brake: Enhances motor control during deceleration and stopping.

Applications

• Industrial Automation: Regulates motor-driven machinery and conveyor systems.

• Process Control: Ensures accurate speed and torque management for various operations.

• Energy Management: Reduces electrical consumption by optimizing motor output.

• Flexible Installations: Works with Allen-Bradley and non-Allen-Bradley equipment.

FAQs

Q1: What is the output power of the 22B-D012N104?
It delivers 5.5 kW or 7.5 HP output with 12A maximum current.

Q2: Which communication options are available?
The drive supports RS-485 communication for integration with automation systems.

Q3: What type of enclosure does it use?
It uses a panel mount IP20/NEMA open-type enclosure suitable for industrial environments.

Q4: Are these drives original and new?
Yes, all 22B-D012N104 drives are original Allen-Bradley products, brand new.

Q5: What is the recommended external protection?
Recommended devices include 140M-D8E-C20 circuit breakers and 100-C23 magnetic contactors.

Q6: How quickly can orders be shipped?
Orders typically ship within 3 days to 2 weeks depending on quantity, via DHL or FedEx.

Q7: Is return supported for defective units?
Yes, we provide 30-day return support for any quality issues.
