Allen-Bradley 22B-D1P4N104 | PowerFlex 40 AC Drive

Specifications

  • Manufacturer: Allen Bradley

  • Product No.: 22B-D1P4N104

  • Condition： 10 Items in Stock

  • Product Type: PowerFlex 40 AC Drive

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 350g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product details

Description

Product Overview

The 22B-D1P4N104 from Allen-Bradley is a PowerFlex 40 Adjustable Frequency AC Drive, designed for precise motor control in industrial applications. It supports Sensorless Vector Control (SVC) and Field Oriented Control (FOC), enabling optimized performance for fans, pumps, conveyors, and machine tools.

Its compact panel-mount design with IP20/NEMA/UL Type Open enclosure ensures easy installation while maintaining protection in standard industrial environments. The drive integrates seamlessly with RS-485 communication networks and provides versatile I/O options for enhanced automation control.

The 22B-D1P4N104 delivers a continuous output power of 0.4 kW (0.5 HP) at 1.4 Amperes, with an output voltage range of 0–460 VAC. Its robust input design accepts 342–528 VAC three-phase power, handling up to 1.8 Amperes continuous current, making it suitable for demanding OEM and industrial installations.

Technical Specifications

Specification Details
Manufacturer Allen-Bradley
Model Number 22B-D1P4N104
Product Line PowerFlex 40
Drive Type Adjustable Frequency AC Drive
Input Voltage 342–528 VAC, 3-phase
Output Power 0.4 kW / 0.5 HP
Output Current 1.4 A
Enclosure Type Panel Mount, IP20, NEMA/UL Type Open
Input Type Keypad
Communication RS-485
Brake Included
I/O Terminal 3 fixed DI (START/STOP/REV), 4 programmable DO, 2 AI, 1 AO
Dimensions (WxHxD) 84 mm x 94 mm x 33 mm
Weight 3.19 lbs (1.45 kg)
Operating Temperature -20°C to 60°C
Certifications CE, UL

Key Features

  • Advanced Vector Control: Supports SVC and FOC for high-performance motor operations.

  • Compact Design: Panel-mount, lightweight, ideal for OEM and industrial machinery.

  • Flexible I/O: Includes programmable digital and analog inputs/outputs.

  • Robust Power Handling: Operates on 342–528 VAC 3-phase supply with 1.4 A output current.

  • Integrated Safety: Brake included for safe operation during deceleration.

Applications

  • Machine tools and industrial automation

  • Fans, pumps, and conveyors requiring precise motor control

  • OEM machinery integration

  • Material handling and process control systems

FAQ

Q1: Is the 22B-D1P4N104 module brand new and original?
Yes, it is fully new, original Allen-Bradley equipment.

Q2: What is the output power and voltage rating?
It provides 0.4 kW (0.5 HP) with 0–460 VAC output voltage.

Q3: What are the input voltage requirements?
The drive accepts 342–528 VAC three-phase supply.

Q4: Does it support advanced motor control features?
Yes, it supports Sensorless Vector Control and Field Oriented Control.

Q5: How many I/O connections are available?
It has 3 fixed digital inputs, 4 programmable digital outputs, 2 analog inputs, and 1 analog output.
