Allen-Bradley 2711-K9C8 | PanelView 900 Standard Operator Terminal

Overview

The Allen-Bradley 2711-K9C8 is a standard PanelView 900 operator terminal designed for industrial human-machine interface applications.

It enables real-time interaction between operators and machines, providing reliable monitoring and control.

This terminal features a 9-inch color TFT display with a cold cathode fluorescent (CCF) backlight, delivering sharp and clear visualization.

Control is achieved through a 16-function key keypad, allowing intuitive operator input for diverse processes.

The terminal includes 310 KB application runtime memory and 1008 KB nonvolatile memory for application objects, text, and bitmaps.

Communication is supported via DH+ and RS-232 printer ports, ensuring seamless integration with existing automation systems.

The 2711-K9C8 operates at 85–264V AC and is enclosed in a durable housing rated NEMA 12/13, 4X, IP54/IP65 for indoor use.

Key Features

• Brand: Allen-Bradley

• Model: 2711-K9C8

• Series: PanelView 900

• Module Type: Standard Operator Terminal

• Display Type: Color TFT with CCF backlight

• Display Size: 9 inches (210 x 131 mm)

• Resolution: 640 x 400 pixels

• Input Type: Keypad (16 function keys F1–F16)

• Communication Ports: DH+, RS232 Printer

• Application Memory: 310 KB runtime, 1008 KB nonvolatile

• Input Voltage: 85–264V AC, 47–63 Hz

• Enclosure: NEMA 12/13, 4X; IP54/IP65 indoor rated

• Status Indicators: Green COMM, Red FAULT

• Backlight Part Number: 2711-NL2

• Communication Cable: 2711-NC14

• Shipping Weight: 9 lbs

• Product Lifecycle Status: Discontinued/Obsolete

Technical Specifications

Advantages

• Enables intuitive operator-machine interaction via 16-key keypad.

• High-resolution 9-inch color TFT display provides clear graphics.

• Supports DH+ and RS-232 printer communication for flexible integration.

• Durable industrial enclosure protects against dust, moisture, and indoor hazards.

• Ample application and nonvolatile memory stores runtime and graphical objects.

• Simple maintenance with replaceable backlight and standardized cables.

FAQ

Q1: Is the Allen-Bradley 2711-K9C8 brand new?
A1: Yes, it is fully new and original from Allen-Bradley.

Q2: What input type does this terminal use?
A2: It uses a 16-function key keypad for operator input.

Q3: What display size and type does it have?
A3: The terminal features a 9-inch color TFT display with CCF backlight.

Q4: Which communication protocols are supported?
A4: DH+ and RS-232 printer ports are supported.

Q5: Can it operate in harsh industrial conditions?
A5: Yes, its NEMA 12/13, 4X, IP54/IP65 enclosure ensures protection indoors.

Q6: What is the memory capacity of the module?
A6: It has 310 KB application runtime memory and 1008 KB nonvolatile memory.

Q7: Is this product still in production?
A7: No, the 2711-K9C8 is discontinued/obsolete but available from stock.
