Allen-Bradley 2711E-K14C6 PanelView 1400E Keypad Terminal

Product Overview

The Allen-Bradley 2711E-K14C6 is a high-performance PanelView 1400E operator terminal with a 14-inch color active-matrix TFT display. Its numeric keypad, arrow keys, and 21 programmable function keys provide flexible operation for industrial control applications.

With DH+ and Remote I/O communications, the 2711E-K14C6 integrates seamlessly with PLC5, SLC500, CompactLogix, and ControlLogix controllers. The key panel uses sealed stainless steel dome membrane switches, rated for 2,000,000 presses, ensuring reliable tactile feedback under demanding environments.

The terminal features a clear, hard-coated, scratch-resistant window over chemically strengthened glass for long-lasting durability. Its NEMA 4X enclosure and stud-mount design provide protection for indoor industrial installations.

Equipped with 2.25 MB memory, the 2711E-K14C6 stores applications and screen data efficiently, while the 6189-NL2 backlight ensures excellent visibility in various lighting conditions.

Technical Specifications

Key Features

• 14-inch Color TFT Display: Provides high clarity and wide viewing angles for operator interfaces.

• Durable Keypad: Stainless steel dome switches with tactile feedback and 2 million presses lifespan.

• Flexible Communication: Supports DH+ and Remote I/O protocols for versatile PLC integration.

• Wide Compatibility: Works with PLC5, SLC500, CompactLogix, and ControlLogix systems.

• Robust Design: Hard-coated, scratch-resistant window and NEMA 4X enclosure protect the terminal.

• Programmable Function Keys: 21 user-defined keys allow screen switching and PLC bit control.

• Reliable Backlight: Ensures visibility in variable lighting environments.

Applications

• Industrial Automation: Interfaces with controllers for process monitoring and control.

• Data Acquisition: Captures and processes input data efficiently for real-time operations.

• Machine Control: Operates machinery through programmable keypad functions.

• Control System Expansion: Integrates with various PLC platforms to expand HMI capabilities.

FAQs

Q1: What display type does the 2711E-K14C6 have?
It features a 14-inch color active-matrix TFT display with 640 × 480 resolution.

Q2: How many function keys are available?
There are 21 user-programmable function keys for task assignments.

Q3: What communication protocols are supported?
It supports DH+ and Remote I/O, compatible with multiple PLC families.

Q4: Are these terminals new and original?
Yes, all units are full original Allen-Bradley products, brand new.

Q5: What is the typical delivery time?
Shipping is within 3 days to 2 weeks, depending on order size, via DHL, FedEx, or UPS.

Q6: Can defective units be returned?
Yes, we provide 30-day return support for any quality issues.
